PT001R-13-LI3-H1131 Turck Pressure Sensors

PT001R-13-LI3-H1131 on Powermatic Associates
Turck

Part#:PT001R-13-LI3-H1131

Alt. Part#:6831615

Manufacturer:Turck

Category:Pressure Sensors

Product Lifecycle:Active

Product description

PT001R-13-LI3-H1131 Turck - PT001R-13-LI3-H1131 Pressure Transmitter, With Current Output (2-Wire)

Product Details

  • Weight
    111 g
  • RoHS
    Yes
  • Country Of Origin
    CHE
  • HTS Code
    9026204000
  • Weight
    111 grams
  • Operating Voltage
    33 volts
  • Ambient Temperature
    -40 degrees celsius, 85 degrees celsius
  • Country of Origin
    Switzerland
  • Pressure transducer material
    Ceramics Al2O3
  • Medium temperature
    -40…+125 °C
  • Protection class
    IP67
  • Housing material
    Stainless-steel/Plastic, 1.4305 (AISI 303)
  • Ambient temperature
    -40…+85 °C
  • Pressure type
    Relative pressure
  • Relative pressure bar
    0…1 bar rel.
  • Process connection
    1/4” NPT-18 male thread
  • Current output
    4…20 mA
  • Electrical connection
    Connector, M12 × 1
  • Electrical output
    Current output (2-wire)
  • Design
    Without display
  • Relative pressure psi
    0…14.5 psi rel.
  • Operating voltage
    8…33 VDC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PT001R-13-LI3-H1131 on Powermatic Associates is $297.70. Order now.

About the product

Pressure Transmitter, With Current Output (2-Wire), , Compact and robust design, Pressure connection with integrated peak pressure aperture, Accuracy hardly affected by temperature within entire range ‐40…+125°C, Excellent EMC properties, Pressure range 0…1 bar rel.
