PS040V-505-LI2UPN8X-H1141 Turck Pressure Sensors
Part#:PS040V-505-LI2UPN8X-H1141
Manufacturer:Turck
Alt. Part#:6832857
Product Lifecycle:Active
Get a quick Quote!
PS040V-505-LI2UPN8X-H1141 Pressure Transmitter (Rotatable), With Analog Output and PNP/NPN Transistor Switching Output, Output 2 Reprogrammable as Switching Output
About the manufacturer: Turck is one of the manufacturers that offers Pressure Sensors that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.
Check out the PS040V-505-LI2UPN8X-H1141 Turck price in the box on the right side or send a quick quote.
Product Details
- Weight 338 g
- Protection class IP67/IP69K
- Pressure transducer material Ceramics Al
2 O3 - Medium temperature -40…+85 °C
- Housing material Stainless-steel/Plastic, 1.4305 (AISI 303)
- Voltage output 0…10 V
- Current output 4…20 mA
- Pressure type Relative pressure
- Ambient temperature -40…+80 °C
- Communication protocol IO-Link
- Electrical connection Connector, M12 × 1
- Design With display
- Operating voltage 18…30 VDC
- Relative pressure psi -14.5…580.15 psi rel.
- Process connection 7/16”-20 UNF
- Electrical output Current output (3-wire), 2 × switching output
- Relative pressure bar -1…40 bar rel.
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
PS040V-505-LI2UPN8X-H1141 Description
Turck PS040V-505-LI2UPN8X-H1141 is a sensor designed for pressure measurement with instrumentation compound pressure sensor capabilities. It features a set point range of 1-100% and a reset point range of 0.5-99.5%, with measurement units available in bar, psi, kPa, MPa, and miscellaneous. The sensor operates within an ambient air temperature range of -40°C to +80°C and has a cylindrical body with a diameter of 34mm. It is pre-equipped with a 4-pin M12 Eurofast QD male connector and a G1/2" (1/2" BSPP) threaded male process port. Part of the PS600 series, it offers an IP67 degree of protection and requires a supply voltage of 18-30Vdc (24Vdc nominal). The sensor's housing and wetted parts are made of 1.4305 (303) stainless steel, with a ceramics Al2O3 pressure transducer and a stainless steel pressure connection. It can measure pressure ranges from -1 to +40bar (-14.5 to +580psi) and supports the IO-Link communication protocol. The fluid medium temperature range is -40°C to +85°C, and it can operate in either NO (Normally Open) or NC (Normally Closed) modes, which are programmable. Protection functions include short-circuit (pulsed) and reverse polarity. The sensor has a response time of 50 - 600ms / 0.05 - 0.6 s, with one analog output (4-20mA; can also be used as a NPN/PNP digital output). Measurement accuracy includes set point accuracy of +/-0.5% FS, analog accuracy of ≤+/-0.5% FS, a response time of <3ms, repeatability of ≤0.5% of the measuring range, and zero shift/span shift of ≤0.15% of the measuring range / °C. It has a current consumption of 50mA and a time delay for ON-delay and OFF-delay of 0-50.
Related documents PS040V-505-LI2UPN8X-H1141 Specs
