FGEN-IM16-5001 Turck Industrial Automation Components

FGEN-IM16-5001 on Powermatic Associates
Turck

Part#:FGEN-IM16-5001

Alt. Part#:6825427

Manufacturer:Turck

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

FGEN-IM16-5001 Turck - FGEN-IM16-5001 Compact multiprotocol I/O module for Ethernet, 16 digital pnp inputs

Product Details

  • Weight
    641 g
  • Country Of Origin
    DEU
  • HTS Code
    8536908530
  • Weight
    641 grams
  • Country of Origin
    Germany
  • Ambient Temperature
    0 degrees celsius, 55 degrees celsius
  • Signal type
    Digital input
  • Connection technology signal
    M12
  • Protection class
    IP67
  • Approvals
    cULus
  • Product Family
    FGEN
  • Fieldbus Protocol
    Modbus TCP, EtherNet/IP, PROFINET
  • Ambient temperature
    0…+55 °C
  • Device type
    Compact station, I/O Module

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of FGEN-IM16-5001 on Powermatic Associates is $617.30. Order now.

About the product

Compact multiprotocol I/O module for Ethernet, 16 digital pnp inputs, , Multiprotocol I/O module for the Ethernet protocols Modbus TCP, EtherNet/IP and PROFINET, PROFINET supports Fast Startup (FSU), Ethernet/IP supports QuickConnect (QC), Integrated Ethernet switch, FDT / DTM supported, Input diagnostics per port, Two inputs per port, , 7/8", 5-pin, for power supply, Power supply, galvanically separated, Fibre-glass reinforced PA6 housing, Vibration and shock-resistant, Encapsulated module electronics, Metal connectors, Degree of protection IP67

FGEN-IM16-5001 Related Documents

English-1630968755646.pdf
