BIM-EG08-AN6X-H1341 Turck Magnetic Field Sensors

Name: BIM-EG08-AN6X-H1341
Brand: Turck
Price: 200 USD
Availability: InStock

Turck BIM-EG08-AN6X-H1341 BIM-EG08-AN6X-H1341 Magnetic Field Sensor, Magnetic-inductive Proximity Sensor

Part#:BIM-EG08-AN6X-H1341

Manufacturer:Turck

Alt. Part#:4621301

Product Lifecycle:Active

In-stock parts: 1

Sep 28, 2024

BIM-EG08-AN6X-H1341 Magnetic Field Sensor, Magnetic-inductive Proximity Sensor

About the manufacturer: Turck is one of the manufacturers that offers Magnetic Field Sensors that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the BIM-EG08-AN6X-H1341 Turck price in the box on the right side or send a quick quote.

Product Details

Weight
22 g
Output function
NO contact, NPN
Special features
Magnetic-inductive
Design
Threaded barrel
Ambient temperature
-25…+70 °C
Protection class
IP67
Rated switching distance
78 mm
Operating voltage
10…30 VDC
Electrical connection
Connector, M12 × 1
Construction size
M8 x 1
Housing material
Stainless steel, 1.4427 SO

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

BIM-EG08-AN6X-H1341 Description

Turck BIM-EG08-AN6X-H1341 is a magnetic field cylinder position sensor/switch belonging to the BIM-EG08 series. This sensor is designed to be embeddable and comes with a 1.4427 (316L) stainless steel housing and a PA12-GF30 (glass fiber reinforced Polyamide) sensing face. It operates on a supply voltage of 10-30Vdc, with nominal values of 12Vdc and 24Vdc. The connection is facilitated by a pre-equipped 4-pin M12 Eurofast QD male connector. Its shape is an M8 fully threaded barrel (Picoprox), ensuring a degree of protection rated at IP67. The sensor can handle a maximum switching frequency of 1kHz / 1000Hz and is designed to operate within an ambient air temperature range of -25°C to +70°C. It features 1 x digital output (10-30Vdc; NPN; 150mA max.) and has a no-load current consumption of 15mA. The sensor is protected against short-circuit (pulsed), overload, and reverse polarity, with a control circuit rated current of 150mA / 0.15 A. The thread size for installation is M8, and it operates in a Normally Open (NO) mode.

$200.00

Stock:

Select Qty:

$200.00

$200.00 each

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
