XVC6B15SK Schneider Electric Industrial Automation Components

XVC6B15SK on Powermatic Associates
Schneider Electric

Part#:XVC6B15SK

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric XVC6B15SK is a monolithic tower light from the XVC6 sub-range, designed with a cylindrical shape and a diameter of 60mm. This 1-tier tower light offers both steady or flashing light options and includes a buzzer that can emit continuous or intermittent sound. It features direct base mounting on horizontal surfaces and provides a degree of protection rated at IP54. The control and supply voltage for this unit are both specified at 24 Vac (AC) and 24 Vdc (DC), respectively. The light color available for this model is red (R).

Product Details

  • Material
    Polycarbonate illuminated unit ABS (acrylonitrile butadiene-styrene) base unit PBT + ABS (UL94HB) top cover
  • Height
    4.76 in (120.8 mm)
  • Net Weight
    0.44 lb(US) (0.2 kg)
  • Flashing Frequency
    1 Hz
  • Fundamental Frequency
    2.23 kHz
  • Current Consumption
    65 mA
  • [Uimp] Rated Impulse Withstand Voltage
    0.8 kV
  • Marking
    CE
  • AWG Gauge
    AWG 22
  • Cable Cross Section
    0.00 in² (0.33 mm²)
  • Cable Length
    33.46 in (850 mm)
  • Product Mounting
    On base
  • Noise Level
    70…85 dB continuous or intermittent tone)1 m
  • Range Of Product
    Harmony XVC6
  • Component Name
    XVC
  • Supply Circuit Type
    AC/DC
  • [Us] Rated Supply Voltage
    24 V
  • Light Source
    LED steady or flashing red
  • Mounting Diameter
    2.36 in (60 mm)
  • Beacon Or Indicator Bank Unit Type
    1 illuminated unit
  • Product Or Component Type
    Complete pre-wired monolithic tower light
  • Sound Signalling
    Buzzer

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of XVC6B15SK on Powermatic Associates is $206.00. Order now.

XVC6B15SK Related Documents

Product Datasheet-1631031048876.pdfCatalog-1631031048881.pdfInstruction Sheet-1631031048897.pdf
