XVC4B4 Schneider Electric Industrial Automation Components

XVC4B4 on Powermatic Associates
Schneider Electric

Part#:XVC4B4

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric XVC4B4 is a monolithic tower light from the XVC4 sub-range, designed for both horizontal and vertical mounting. This pre-assembled and pre-cabled tower light features a cylindrical shape with a diameter of 40mm and includes four tiers of steady light. It supports a control voltage of 24 Vac and a supply voltage of both 24 V AC and DC. The XVC4B4 offers light colors in red, orange, green, and blue (ROGB). It is equipped with a degree of protection rated at IP54 for general use and IP23 when mounted on a vertical surface.

Product Details

  • Material
    Polycarbonate illuminated unit ABS (acrylonitrile butadiene-styrene) base unit PBT + ABS (UL94HB) top cover SGP (chromium-plated) support tube
  • Light Source
    LED steady red LED steady orange LED steady green LED steady blue
  • Net Weight
    1.23 lb(US) (0.56 kg)
  • AWG Gauge
    AWG 22
  • Current Consumption
    100 mA
  • [Uimp] Rated Impulse Withstand Voltage
    0.8 kV
  • Cable Cross Section
    0.00 in² (0.33 mm²)
  • Product Mounting
    On support tube, 17 mm
  • Mounting Location
    On support tube, 17 mm
  • [Us] Rated Supply Voltage
    24 V
  • Beacon Or Indicator Bank Unit Type
    4 illuminated units
  • Range Of Product
    Harmony XVC4
  • Sound Signalling
    Without
  • Flashing Frequency
    1 Hz
  • Height
    20.02 in (508.5 mm)
  • Marking
    CE
  • Cable Length
    23.62 in (600 mm)
  • Device Short Name
    XVC
  • Component Name
    XVC
  • Supply Circuit Type
    AC/DC
  • Mounting Diameter
    1.57 in (40 mm)
  • Product Or Component Type
    Complete pre-wired monolithic tower light

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of XVC4B4 on Powermatic Associates is $284.00. Order now.
