QO2801042 Schneider Electric Miniature Circuit Breakers (MCBs)

QO2801042 on Powermatic Associates
Schneider Electric

Part#:QO2801042

Manufacturer:Schneider Electric

Category:Miniature Circuit Breakers (MCBs)

Product Lifecycle:Active

Get a quick Quote!

Square D by Schneider Electric QO2801042 is a Miniature Circuit Breaker (MCB) featuring a shunt trip coil. It is designed for plug-in mounting and has a rated current of 80A with a plug-in connection type. This MCB operates at a rated voltage of 120V to 240V AC and is compatible with a wire cross-section of 4-2/0AWG for one aluminum or copper cable. It is a 2-pole device with a control voltage range of 12Vdc to 24Vdc. The short circuit breaking rating is specified at 10kA for 240Vac and 5kA for 48Vdc, utilizing box lugs as the type of terminals.

About the manufacturer: Schneider Electric is one of the manufacturers that offers Miniature Circuit Breakers (MCBs) that you can order at Powermatic Associates site. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.

Check out the QO2801042 Schneider Electric price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

QO2801042 Description

Square D by Schneider Electric QO2801042 is a Miniature Circuit Breaker (MCB) featuring a shunt trip coil. It is designed for plug-in mounting and has a rated current of 80A with a plug-in connection type. This MCB operates at a rated voltage of 120V to 240V AC and is compatible with a wire cross-section of 4-2/0AWG for one aluminum or copper cable. It is a 2-pole device with a control voltage range of 12Vdc to 24Vdc. The short circuit breaking rating is specified at 10kA for 240Vac and 5kA for 48Vdc, utilizing box lugs as the type of terminals.
