M9U21150 Schneider Electric Industrial Automation Components

Product Details

• Breaking Capacity
  10 kA Icu 220 V DC EN/IEC 60947-2 6 kA Icu 250 V DC EN/IEC 60947-2 20 kA Icu 110 V DC EN/IEC 60947-2 5 kA AIR 12...250 V DC UL 1077 10 kA Icu 220 V DC GB 14048.2 6 kA Icu 250 V DC GB 14048.2 20 kA Icu 110 V DC GB 14048.2
• [Ics] Rated Service Breaking Capacity
  7.5 kA 75 % EN/IEC 60947-2 - 220 V DC 4.5 kA 75 % EN/IEC 60947-2 - 250 V DC 15 kA 75 % EN/IEC 60947-2 - 110 V DC 7.5 kA 75 % GB 14048.2 - 220 V DC 4.5 kA 75 % GB 14048.2 - 250 V DC 15 kA 75 % GB 14048.2 - 110 V DC
• [Ue] Rated Operational Voltage
  250 V DC 110 V DC 220 V DC
• Standards
  EN/IEC 60947-2 GB 14048.2 UL 1077
• Product Certifications
  IEC CCC UR
• Electrical Durability
  3000 cycles 250 V DC L/R = 2 ms 6000 cycles 250 V DC
• Connections - Terminals
  Tunnel type terminal top or bottom) 0.00…0.05 in² (1…35 mm²) AWG 18...AWG 2) - rigid stranded Tunnel type terminal top or bottom) 0.00…0.04 in² (1…25 mm²) AWG 18...AWG 4) - flexible Tunnel type terminal top or bottom) 0.00…0.04 in² (1…25 mm²) AW
• Tightening Torque
  30.98 lbf.in (3.5 N.m) top or bottom
• Color
  Gray
• Control Type
  Toggle
• Wire Stripping Length
  0.55 in (14 mm) top or bottom
• Earth-Leakage Protection
  Without
• Provision For Padlocking
  Padlockable
• Mechanical Durability
  20000 cycles
• Net Weight
  0.28 lb(US) (0.128 kg)
• Depth
  2.87 in (73 mm)
• Width
  0.71 in (18 mm)
• Height
  3.19 in (81 mm)
• 9 Mm Pitches
  2
• Mounting Support
  DIN rail
Local Signalling
ON/OFF indication
Contact Position Indicator
Yes
Mounting Mode
Clip-on
[Ui] Rated Insulation Voltage
500 V DC EN/IEC 60947-2
[Uimp] Rated Impulse Withstand Voltage
6 kVEN/IEC 60947-2
Magnetic Tripping Limit
7...10 x In DC
Suitability For Isolation
Yes EN/IEC 60947-2
Utilisation Category
Category A EN/IEC 60947-2
Curve Code
C
Trip Unit Technology
Thermal-magnetic
Number Of Protected Poles
1
Line Rated Current
50 A 77 °F (25 °C) EN/IEC 60947-2
Network Type
DC
Poles Description
1P
Product Or Component Type
Miniature circuit-breaker
Range
Multi 9
Device Short Name
C60H-DC
Device Application
Distribution
Product Name
Multi 9 C60H-DC
