ATV71HU30N4S337 Schneider Electric Variable Frequency Drives (VFD)

Schneider Electric ATV71HU30N4S337 Schneider Electric ATV71HU30N4S337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series, designed to offer variable speed and frequency control with a U/F ratio of 2 points or 5 points, sensorless flux vector control, ENA System, and vector control with or without speed feedback. It can deliver 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. This model features a built-in DC choke, EMC filter, and a heatsink, with a coated version for enhanced chemical resistance. It operates on a supply voltage of 323-528Vac (380Vac / 400Vac / 480Vac / 500Vac nom.), with dimensions of H260mm x W155mm x D187mm. It offers an IP20 UL type 1 degree of protection and has a rated current of 7.8A at 380Vac (4kHz), 6.2A at 460Vac (4kHz), with a maximum current of 12.9A for 2 seconds and 11.7A for 60 seconds. The ATV71HU30N4S337 supports wall mounting, uses Modbus and CANopen communication protocols, and is designed for a 3-phase network with an output frequency range of 0.1-599 Hz. It includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 programmable digital input and 1 PWR safety input, 3 digital outputs, and 2 analog inputs for comprehensive connectivity and control. The current consumption is rated at 10.7A for 380Vac and 9A for 480Vac, with a rated active power of 3kW.
Schneider Electric

Part#:ATV71HU30N4S337

Manufacturer:Schneider Electric

Product Lifecycle:Active

Get a quick Quote!

Schneider Electric ATV71HU30N4S337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series, designed to offer variable speed and frequency control with a U/F ratio of 2 points or 5 points, sensorless flux vector control, ENA System, and vector control with or without speed feedback. It can deliver 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. This model features a built-in DC choke, EMC filter, and a heatsink, with a coated version for enhanced chemical resistance. It operates on a supply voltage of 323-528Vac (380Vac / 400Vac / 480Vac / 500Vac nom.), with dimensions of H260mm x W155mm x D187mm. It offers an IP20 UL type 1 degree of protection and has a rated current of 7.8A at 380Vac (4kHz), 6.2A at 460Vac (4kHz), with a maximum current of 12.9A for 2 seconds and 11.7A for 60 seconds. The ATV71HU30N4S337 supports wall mounting, uses Modbus and CANopen communication protocols, and is designed for a 3-phase network with an output frequency range of 0.1-599 Hz. It includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 programmable digital input and 1 PWR safety input, 3 digital outputs, and 2 analog inputs for comprehensive connectivity and control. The current consumption is rated at 10.7A for 380Vac and 9A for 480Vac, with a rated active power of 3kW.

About the manufacturer: Schneider Electric is one of the manufacturers that offers Variable Frequency Drives (VFD) that you can order at Powermatic Associates site. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.

Check out the ATV71HU30N4S337 Schneider Electric price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

ATV71HU30N4S337 Description

Schneider Electric ATV71HU30N4S337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series, designed to offer variable speed and frequency control with a U/F ratio of 2 points or 5 points, sensorless flux vector control, ENA System, and vector control with or without speed feedback. It can deliver 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. This model features a built-in DC choke, EMC filter, and a heatsink, with a coated version for enhanced chemical resistance. It operates on a supply voltage of 323-528Vac (380Vac / 400Vac / 480Vac / 500Vac nom.), with dimensions of H260mm x W155mm x D187mm. It offers an IP20 UL type 1 degree of protection and has a rated current of 7.8A at 380Vac (4kHz), 6.2A at 460Vac (4kHz), with a maximum current of 12.9A for 2 seconds and 11.7A for 60 seconds. The ATV71HU30N4S337 supports wall mounting, uses Modbus and CANopen communication protocols, and is designed for a 3-phase network with an output frequency range of 0.1-599 Hz. It includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 programmable digital input and 1 PWR safety input, 3 digital outputs, and 2 analog inputs for comprehensive connectivity and control. The current consumption is rated at 10.7A for 380Vac and 9A for 480Vac, with a rated active power of 3kW.

Manufacturer warranty

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?
