9007DA3

Schneider Electric

Product Lifecycle: Active

LMT SW ONE-WAY ROLLER LEVER ARM 2 1/2IN

9007DA3

LMT SW ONE-WAY ROLLER LEVER ARM 2 1/2IN

Friendly Powermatic robot holding a hammer

We're always improving how we show product data for you!

If you need more product info, just chat with us.

We're here to assist.

Get a quick quote

Select Qty:

Average response time:

11 minutes

This part can ship within 24h!

Fast worldwide Shipping and Delivery

Shipping cost will be calculated during checkout


Payments methods

Secure Payment Processing
with money back guarantee

1 year warranty on all parts


Responsive Customer Support
with personalized assistance


Need more details?

Feel free to chat with us.

Relevant products

This item can ship within 24h!

LGF36600U31XAAUOYH1

LGF36600U31XAAUOYH1

Square D by Schneider Electric LGF36600U31XAAUOYH1 is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT LGF sub-range. It features a factory-installed 24Vdc undervoltage (U/V) trip release coil and a factory-installed 1A/1B (1NO+1NC) auxiliary switch OF wire harness. Designed for PowerPacT L-Frame 600 Micrologic 3.3 (LI), this 3-pole (3P) circuit breaker is rated for 600A and 600Vac, with a busbar rating of 80% and an 18kA busbar. It offers long-time (L) and instantaneous (I) protection functions, with a rated insulation voltage (Ui) of 750 V and a rated voltage (AC) of 600Vac 600Y/347Vac. The unit is designed for individual unit mount on plate, with a net height of 382 mm, width of 153 mm, and depth of 171 mm. It has an IP40 degree of protection and operates manually via a toggle. Protection settings include L - Protection against overload adjustable from 0.3 to 1 x In (50A to 150A) and I - Instantaneous protection against short-circuit adjustable from 1.5 to 11 x In (900A to 6600A). The control voltage (AC) specification indicates that the circuit breaker opens instantaneously when the undervoltage trip supply voltage drops between 35% and 70% of its rated control voltage, allowing closing when the supply voltage reaches 85% of rated control voltage. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 600 AT, with a frame current rating of 600 AF. It has a short circuit breaking rating of 65kA at 240Vac, 35kA at 480Vac, 35kA at 480Y/277Vac, 18kA at 600Vac, 18kA at 600Y/347Vac, and 20kA at 500Vdc, all according to UL489 standards. The trip unit type is an electronic Micrologic Standard 3.3 (LI) with LI protection and no display, categorized under utilisation category A.

Schneider ElectricSTOCK: 3

This item can ship within 24h!

HDF36150

HDF36150

Square D by Schneider Electric HDF36150 is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HDF sub-range, featuring a PowerPact H-Frame 150 TMD design. It is a 3-pole (3P) device with a rated current of 150A and offers thermal protection for overload and magnetic protection for short-circuit scenarios. This breaker is designed for a 600Vac/250Vdc operation with a 14kA busbar at 80% rating and includes a terminal nut kit for fixed busbar connections on both line and load sides. It has a rated insulation voltage (Ui) of 750 V, with AC and DC rated voltages of 600Vac 600Y/347Vac and 250Vdc, respectively. The unit is designed for individual mounting on a plate, with dimensions of 163 mm in height, 104 mm in width, and 86 mm in depth. It features an IP40 degree of protection, a toggle (manual) operating mode, and fixed protection settings for over-current at 150A and short-circuit hold and trip currents at 900A and 1700A, respectively. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 150 AT, with a frame current rating of 150 AF, and it has a short circuit breaking rating that varies depending on the voltage, including 25kA at 240Vac, 18kA at 480Vac and 480Y/277Vac, 14kA at 600Vac and 600Y/347Vac, and 20kA at 250Vdc, all in accordance with UL489. The trip unit type is thermal-magnetic (fixed) without a display, and it falls under utilisation category A.

Schneider ElectricSTOCK: 1
