PILZ-506312 Pilz Safety Switches

PILZ-506312 on Powermatic Associates
Pilz

Part#:PILZ-506312

Manufacturer:Pilz

Category:Safety Switches

Product Lifecycle:Active

Product description

Pilz PILZ-506312 is a non-contact magnetic safety door switch designed for electronic/electromechanical relay applications. It operates within an ambient air temperature range of -10 to +55°C and features a single connection design. This switch is pre-wired with a 13cm pigtail that terminates with a 5-pin M12 connector. With dimensions of W26.4mm x H37mm x L18mm, it offers a square shape and is constructed with a yellow PBT housing, ensuring a degree of protection rated at IP65 and IP67. The PILZ-506312 operates at a rated voltage of 24Vdc and offers a sensing distance of 3mm or 10mm, depending on the actuator used. It includes 3 Normally Open (NO) auxiliary contacts, with the contact configuration comprising 2NO (safety contacts; reed) and 1NO (auxiliary contact), and does not include Normally Closed (NC) auxiliary contacts.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty

PILZ-506312 Pilz

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

About the manufacturer

Pilz

Powermatic Associates is an authorized Pilz distributor, committed to bringing you the highest standards in industrial automation and safety technology. Pilz is a renowned manufacturer specializing in innovative solutions for safe automation. Their expertise lies in developing products that secure your machinery and processes, ensuring high productivity while safeguarding both human workers and eq...

Recently viewed products

Relevant products

FAQ

Out if stock but available for backorder.

Pilz PILZ-506312 is a non-contact magnetic safety door switch designed for electronic/electromechanical relay applications. It operates within an ambient air temperature range of -10 to +55°C and features a single connection design. This switch is pre-wired with a 13cm pigtail that terminates with a 5-pin M12 connector. With dimensions of W26.4mm x H37mm x L18mm, it offers a square shape and is constructed with a yellow PBT housing, ensuring a degree of protection rated at IP65 and IP67. The PILZ-506312 operates at a rated voltage of 24Vdc and offers a sensing distance of 3mm or 10mm, depending on the actuator used. It includes 3 Normally Open (NO) auxiliary contacts, with the contact configuration comprising 2NO (safety contacts; reed) and 1NO (auxiliary contact), and does not include Normally Closed (NC) auxiliary contacts.
