EX-F1-C5 Panasonic Level Sensors

EX-F1-C5 on Powermatic Associates
Panasonic

Part#:EX-F1-C5

Manufacturer:Panasonic

Category:Level Sensors

Product Lifecycle:Active

Get a quick Quote!

Panasonic EX-F1-C5 is a pipe-mountable liquid level photoelectric sensor with a built-in amplifier, designed for detecting liquid levels within pipes of 6-13mm diameter. It features a polycarbonate housing, nylon tying band, and silicone anti-slip tube for secure installation. The sensor consumes 30mA / 0.03 A of current and provides quick response times of 2ms / 0.002 s. For easy monitoring, it includes a red LED visual position indicator. It offers 1 x digital output (NPN open-collector / 24Vdc / 100mA) for signal transmission. The sensor is pre-wired with a 5m 3-core 0.1mm2 cabtyre cable, terminated with bare flying leads for convenient connection.

About the manufacturer: Panasonic is one of the manufacturers that offers Level Sensors that you can order at Powermatic Associates site. Panasonic is a leading supplier of cutting-edge automation control solutions that are both advanced and cost-effective. With a significant presence in a variety of industrial sectors globally, including automotive, semiconductor, packaging, and OEMs, our product lineup features PLCs, HMI, and other offerings.

Check out the EX-F1-C5 Panasonic price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

EX-F1-C5 Description

Panasonic EX-F1-C5 is a pipe-mountable liquid level photoelectric sensor with a built-in amplifier, designed for detecting liquid levels within pipes of 6-13mm diameter. It features a polycarbonate housing, nylon tying band, and silicone anti-slip tube for secure installation. The sensor consumes 30mA / 0.03 A of current and provides quick response times of 2ms / 0.002 s. For easy monitoring, it includes a red LED visual position indicator. It offers 1 x digital output (NPN open-collector / 24Vdc / 100mA) for signal transmission. The sensor is pre-wired with a 5m 3-core 0.1mm2 cabtyre cable, terminated with bare flying leads for convenient connection.

Manufacturer warranty

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

Relevant products

EX-13EB on Powermatic Associates

EX-13EB

Verified stock: 137

Panasonic EX-13EB is a photo-electric sensor designed with a polyethylene terephthalate housing and a polyalylate lens. It operates with a current consumption of 10mA / 0.01 A for both the emitter and receiver. This sensor offers a degree of protection rated at IP67 and emits red light with a wavelength of 680 nm. It is capable of detecting opaque objects as small as 2mm / 0.079". The EX-13EB features an orange LED that lights up when the output is ON and a green LED that indicates a stable light received or stable dark condition. It has a quick response time of 0.5ms / 0.0005 s and includes 1 digital output (NPN open-collector / 24Vdc / 50mA). Designed for Dark-ON operating mode, it has a sensing distance of 0.5m / 50cm / 500mm / 19.685". The sensor is equipped with output short-circuit protection and is described as an ultra-slim photo-electric sensor emitter+receiver pair with side sensing and built-in amplification. It comes pre-wired with a 2m 3-core (2-core on emitter side) 0.1mm2 flexible cabtyre cable terminated with bare end flying leads.

Panasonic

EX-14A-PN on Powermatic Associates

EX-14A-PN

Verified stock: 79

Panasonic EX-14A-PN is a photo-electric sensor designed with a polyethylene terephthalate housing and a polyalylate lens. It operates with a current consumption of 13mA / 0.013 A and offers a degree of protection rated at IP67. This sensor emits red light and is capable of detecting opaque objects as small as 0.1mm / 0.004". It features an orange LED visual position indicator that lights up when the output is ON and a green LED that indicates a stable light received or stable dark condition. The response time of the EX-14A-PN is 0.5ms / 0.0005 s, and it includes 1 x digital output (PNP open-collector / 24Vdc / 50mA) for connectivity. It operates in a Light-ON mode and has a sensing distance ranging from 0.2cm to 2.5cm (2mm-25mm / 0.079"-0.984"). This sensor is equipped with output short-circuit protection and is described as an ultra-slim photoelectric sensor with front sensing and built-in amplification. It connects via a pre-wired 2m 3-core 0.1mm2 flexible cabtyre cable terminated with bare end flying leads. The wavelength of the emitted light is 680 nm.

Panasonic

EX-13EA on Powermatic Associates

EX-13EA

Verified stock: 52

Panasonic EX-13EA is a photo-electric sensor designed with a polyethylene terephthalate housing and a polyalylate lens. It operates with a current consumption of 10mA / 0.01 A for both the emitter and receiver. This sensor is characterized by an IP67 degree of protection, ensuring its operation in various environmental conditions. It emits red light with a wavelength of 680 nm and can detect opaque objects as small as 2mm / 0.079". The EX-13EA features an orange LED that lights up when the output is ON and a green LED that indicates a stable light received or stable dark condition. It has a rapid response time of 0.5ms / 0.0005 s and includes 1 digital output (NPN open-collector / 24Vdc / 50mA). The operating mode is Light-ON, and it has a sensing distance of 0.5m / 50cm / 500mm / 19.685". For protection, it includes outputs short-circuit protection. This ultra-slim photo-electric sensor emitter+receiver pair is designed for side sensing with built-in amplification. It comes pre-wired with a 2m 3-core (2-core on emitter side) 0.1mm2 flexible cabtyre cable terminated with bare end flying leads.

Panasonic
