MDI4MRQ23A7-EQ Novanta IMS Stepper Motors

MDI4MRQ23A7-EQ on Powermatic Associates
Novanta IMS

Part#:MDI4MRQ23A7-EQ

Manufacturer:Novanta IMS

Category:Stepper Motors

Product Lifecycle:Active

Product description

Novanta IMS MDI4MRQ23A7-EQ is a stepper motor that features an integrated driver and operates as a 2-phase DC stepper motor. It is designed with an external single-end 512-line optical encoder and includes a single motor stack with expanded features in the Plus 2 version. This part offers connectivity through a 19-pin M23 male connector and a 5-pin M12 male connector, supporting RS-422 and RS-485 communication protocols. It operates on a supply voltage range of 12Vdc to 75Vdc, with specific ratings at 24Vdc, 48Vdc, and 72Vdc. The motor is mounted using a 57x57mm flange and can operate in ambient air temperatures ranging from 0 to +85°C. It is protected to a degree of IP65, ensuring protection against dust ingress and low-pressure water jets. The motor has a moment of inertia of 0.18kg.cm^2, a stall torque of 64N.cm, and a resolution characterized by a 1.8° step angle.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty

MDI4MRQ23A7-EQ Novanta IMS

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

About the manufacturer

Novanta IMS

Powermatic Associates is an authorized Novanta IMS distributor, proudly presenting a diverse array of industrial solutions designed to optimize and elevate your operations. Novanta IMS, a recognized leader in innovation and precision, specializes in the development and production of sophisticated motion control systems that are essential across numerous industries. Their comprehensive portfolio fe...
