ABP-1412 Integra Enclosures Electrical Enclosures

ABP-1412 on Powermatic Associates
Integra Enclosures

Part#:ABP-1412

Manufacturer:Integra Enclosures

Product Lifecycle:Active

In-stock parts: 27

Nov 16, 2024

Integra ABP-1412 is a standard mounting panel designed to fit 14"x12" enclosures. This mounting plate is made from aluminium, ensuring compatibility with various applications. It features dimensions of H12.75" x W10.88", specifically crafted to serve as an aluminium back panel or mounting plate within the specified enclosure size.

About the manufacturer: Integra Enclosures is one of the manufacturers that offers Electrical Enclosures that you can order at Powermatic Associates site. Integra Enclosures specializes in crafting custom-engineered thermoplastic electrical enclosures for diverse industries such as electrical construction, water treatment, telecommunications, instrumentation, utility, and more.

Check out the ABP-1412 Integra Enclosures price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

This item can ship within 24h!

Manufacturer warranty

$34.00

Stock:

27

Select Qty:

$34.00

$34.00 each

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
