DSNU-5/16-1-P-A Festo Pneumatic Cylinders

DSNU-5/16-1-P-A on Powermatic Associates
Festo

Part#:DSNU-5/16-1-P-A

Manufacturer:Festo

Category:Pneumatic Cylinders

Product Lifecycle:Active

Product description

Festo DSNU-5/16-1-P-A is a double-acting single-ended pneumatic cylinder designed for mounting via accessories. It features a round cylindrical shape with a bore size of 5/16" (B5/16") and a stroke length of 1" (S1"). The cylinder is constructed from high-alloy stainless steel for the cylinder barrel and piston rod, with a wrought aluminium alloy cover, and uses nitrile rubber (NBR) and thermoplastic polyurethane (TPE-U(PU)) for static seals. It operates within an ambient air temperature range of -20°C to +80°C and offers moderate-corrosion stress resistance (CRC Class 2). This model is part of the DSNU Imperial/Inch series, designed based on ISO6432, featuring built-in magnets, elastic cushioning at both ends, and the capability for operation with oil lubrication. Position sensing is achievable via a proximity sensor. The cylinder uses compressed air as per ISO8573-1:2010 [7;4;4] standards, with a connection type of 6-32 UNC-2A male threaded rod and 10-32UNF threaded pneumatic port. It operates at a pressure range of +1 to +10 bar.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty

DSNU-5/16-1-P-A Festo

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

About the manufacturer

Festo

Powermatic Associates is an authorized Festo distributor, proudly offering a wide array of Festo's innovative industrial automation products and solutions. Festo is a globally recognized leader in automation technology and pneumatic solutions, renowned for their commitment to quality, efficiency, and sustainability. With a vast portfolio ranging from actuators, valves, sensors, and connectors to e...

Recently viewed products

MDI4MRQ34B2-EQ on Powermatic Associates

MDI4MRQ34B2-EQ

Novanta IMS

Novanta IMS MDI4MRQ34B2-EQ is a stepper motor within the Stepper motors sub-range, featuring an integrated driver and a 2-phase AC stepper motor design. It is equipped with an external single-end 512-line optical encoder and a double (2) motor stack, Plus 2 version for expanded features. The connection is facilitated through a 19-pin M23 male connector and a 5-pin M12 female connector, supporting RS-422 and RS-485 communication protocols. This stepper motor operates on a 240Vac supply voltage and is designed for mounting with an 85x85mm flange. It can operate in ambient air temperatures ranging from 0 to +85°C and has a degree of protection rated at IP65. The moment of inertia is specified at 1.6kg.cm2, with a stall torque of 353N.cm, and a resolution characterized by a 1.8° step angle.

0 in stock

Relevant products

FAQ

Out if stock but available for backorder.

Festo DSNU-5/16-1-P-A is a double-acting single-ended pneumatic cylinder designed for mounting via accessories. It features a round cylindrical shape with a bore size of 5/16" (B5/16") and a stroke length of 1" (S1"). The cylinder is constructed from high-alloy stainless steel for the cylinder barrel and piston rod, with a wrought aluminium alloy cover, and uses nitrile rubber (NBR) and thermoplastic polyurethane (TPE-U(PU)) for static seals. It operates within an ambient air temperature range of -20°C to +80°C and offers moderate-corrosion stress resistance (CRC Class 2). This model is part of the DSNU Imperial/Inch series, designed based on ISO6432, featuring built-in magnets, elastic cushioning at both ends, and the capability for operation with oil lubrication. Position sensing is achievable via a proximity sensor. The cylinder uses compressed air as per ISO8573-1:2010 [7;4;4] standards, with a connection type of 6-32 UNC-2A male threaded rod and 10-32UNF threaded pneumatic port. It operates at a pressure range of +1 to +10 bar.
