8113317 Festo Cable Assemblies

8113317 on Powermatic Associates
Festo

Part#:8113317

Alt. Part#:NEBM-F1W31-XC-0.2-F1N-DF1W31

Manufacturer:Festo

Category:Cable Assemblies

Product Lifecycle:Active

Product description

motor cable NEBM-F1W31-XC-0.2-F1N-DF1W31 Cable identification: Without inscription label holder, Connection frequency: 30, Product weight: 11 g, Electrical connection 1, function: Field device side, Electrical connection 1, design: Angular

Product Details

  • Information on bending radius, fixed cable installation
    Can be bent once
  • Electrical connection 1, design
    Rectangular
  • Electrical connection 2, function
    Control side
  • Electrical connection 2, design
    Rectangular
  • Electrical connection 2, connection pattern
    00995930
  • Cable characteristic
    for dynamic applications
  • Cable design
    31 wires, distance 0.5 mm
  • Degree of protection
    IP20
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Material of cable sheath
    PET
  • Type code
    NEBM
  • Contact durability
    30
  • Electrical connection 1, connection technology
    Connection diagram F1
  • Electrical connection 1, occupied pins/wires
    31
  • Electrical connection 2, number of pins/wires
    31
  • DC operating voltage range
    0 V ... 50 V
  • Bending radius, fixed cable installation
    0 mm
  • Ambient temperature
    -20 °C ... 75 °C
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Material of pin contacts
    Copper alloy, tin-plated
  • Electrical connection 2, note on cable outlet
    90°
  • Cable designation
    Without label holder
  • Electrical connection 1, number of pins/wires
    31
  • Electrical connection 2, connection type
    Socket
  • Electrical connection 2, occupied pins/wires
    31
  • Current rating at 40°C
    0.5 A
  • Connector cable test conditions
    Test conditions on request
  • Ambient temperature with flexible cable installation
    -5 °C ... 70 °C
  • Color cable sheath
    Gray
  • Product weight
    11 g
  • Electrical connection 1, connection type
    Socket
  • Electrical connection 1, type of mounting
    Snap-locking
  • Electrical connection 2, connection technology
    Connection diagram F1
  • Electrical connection 2, type of mounting
    Snap-locking
  • Surge resistance
    0.25 kV
  • Nominal conductor cross section
    0.0105 mm²
  • CE marking (see declaration of conformity)
    As per EU RoHS directive
  • Storage temperature
    -25 °C ... 55 °C
  • Housing colour
    Black
  • Electrical connection 1, information on cable outlet
    90°
  • Electrical connection 1, function
    Field device end
  • Electrical connection 1, cable outlet
    Angled
  • Electrical connection for input 1, connection pattern
    00995930
  • Electrical connection 2, cable outlet
    Angled
  • Nominal operating voltage DC
    24 V
  • Cable length
    0.2 m
  • Bending radius, flexible cable installation
    ≥ 25 mm
  • Note on degree of protection
    In mounted state
  • Contamination level
    1
  • Housing material
    PA

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
