8110772 Festo Pneumatic Components
Part#:8110772
Alt. Part#:DFPC-125-150-D
Manufacturer:Festo
Category:Pneumatic Components
Product Lifecycle:Active
Product description
linear drive DFPC-125-150-D Size of actuator: 125, Flange hole pattern: F10, Stroke: 150 mm, Piston diameter: 125 mm, Fitting connection conforms to standard: ISO 5210
Product Details
- Size of valve actuator 125
- Operating pressure 0.6 bar ... 8 bar
- Piston diameter 125 mm
- Cushioning Elastic cushioning rings/pads at both ends
- Position sensing For proximity sensor
- Air consumption, retracting, per 10 mm stroke 0.825 l
- Type of mounting Optionally: With spacer bolt
- Piston rod material High-alloy stainless steel
- Type code DFPC
- Symbol 00991217
- Theoretical force at 6 bar, retracting 7069 N
- Additional weight per 10 mm stroke 107.4 g
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Material of cylinder barrel Wrought aluminum alloy, smooth-anodized
- Shock resistance Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
- Stroke 150 mm
- Design Piston Cylinder barrel
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Air consumption advancing per 10 mm stroke 0.859 l
- Product weight 4580 g
- Piston rod wiper seal material TPE-U(PU)
- Tie rod material High-alloy stainless steel
- Vibration resistance Transport application test with severity level 1 as per FN 942017-4 and EN 60068-2-6
- Standard connection for valve ISO 5210
- Mode of operation Double-acting
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Moving mass at 0 mm stroke 1059.6 g
- Basic weight with 0 mm stroke 2968.9 g
- Pneumatic connection G1/8
- Static seal material NBR
- Impact energy in the end positions 1.1 J
- Nominal operating pressure 6 bar
- Flange hole pattern F10
- Mounting position Any
- Ambient temperature -20 °C ... 80 °C
- Theoretical force at 6 bar, advancing 7363 N
- Additional moving mass per 10 mm stroke 38.9 g
- Cover material Gravity die-cast aluminum
- Nut material High-alloy stainless steel
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
