8093817 Festo Air Gap Sensors

Product Details

• Electrical connection 1, type of mounting
  Screw-type lock
• KC characters
  KC EMC
• Analog output
  4 - 20 mA
• Repetition accuracy in ± µm
  2.5 µm
• Note on materials
  Free of copper and PTFE RoHS-compliant
• Supply pressure
  0.8 bar ... 1.6 bar
• Ambient temperature
  0 °C ... 50 °C
• Electrical connection 1, connection type
  Plug
• Detected variable
  Gap
• Max. load resistance of current output
  500 Ohm
• CE marking (see declaration of conformity)
  As per EU EMC directive As per EU RoHS directive
• Information on operating and pilot media
  Operation with oil lubrication possible (required for further use)
• Switching function
  Window comparator Threshold value with variable hysteresis
• Max. output current
  100 mA
• IO-Link®, profile
  Smart sensor profile
• Type of mounting
  Optionally: With H-rail
• Product weight
  60 g
• Protection against tampering
  Electronic interlock
• Type code
  SOPA
• Electrical connection 1, number of pins/wires
  5
Symbol
00997316
Certification
RCM compliance mark
Sensing range
20 µm ... 200 µm
Switching output
PNP/NPN switchable
Short-circuit protection
yes
IO-Link®, process data width IN
2 Byte
Pneumatic connection
QS-6
DC operating voltage range
20 V ... 30 V
Setting options
IO-Link® Via display and pushbuttons
Electrical connection for input 1, connection pattern
00991172
Distance characteristic curve start value
0 µm
Distance characteristic curve end value
300 µm
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Switching element function
N/C contact/N/O contact switchable
IO-Link®, SIO mode support
Yes
IO-Link®, process data width OUT
0 Byte
IO-Link®, minimum cycle time
3 ms
Display type
Illuminated LCD, multi-color
Electrical connection 1, connection technology
M12x1 A-coded as per EN 61076-2-101
Rise time
22 ms
Measuring principle
Pneumatic
Protocol
IO-Link®
IO-Link®, communication mode
COM2 (38,4 kBd)
IO-Link®, port class
A
IO-Link®, data memory required
< 500 byte
Reverse polarity protection
for all electrical connections
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
IO-Link®, protocol version
Device V 1.1
IO-Link®, function classes
Process data variable (PDV) Switching signal channel (SSC)
IO-Link®, process data content IN
2-bit SSC (distance monitoring) 10-bit PDV (distance)
IO-Link®, service data contents IN
14-bit supply pressure
Housing material
PA-reinforced
Degree of protection
IP65
