8089048 Festo Ball Valves

Name: 8089048
Brand: Festo

Festo 8089048 ball valve VZBE-4-WA-63-T-2-F1012-V15V15 Design structure: 2-way ball valve, Type of actuation: mechanical, Sealing principle: soft, Assembly position: Any, Mounting type: Line installation

Part#:8089048

Manufacturer:Festo

Alt. Part#:VZBE-4-WA-63-T-2-F1012-V15V15

Product Lifecycle:Active

Get a quick Quote!

ball valve VZBE-4-WA-63-T-2-F1012-V15V15 Design structure: 2-way ball valve, Type of actuation: mechanical, Sealing principle: soft, Assembly position: Any, Mounting type: Line installation

About the manufacturer: Festo is one of the manufacturers that offers Ball Valves that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 8089048 Festo price in the box on the right side or send a quick quote.

Product Details

Actuation type
Mechanical
Switching position indication
Slot direction = flow direction
Flow direction
Reversible
Based on norm
ASME B16.11 ISO 5211
Note on materials
Contains paint-wetting impairment substances RoHS-compliant
Material number of housing
1.4408/CF8M
Shaft material
High-alloy stainless steel
Type code
VZBE
Sealing principle
Soft
Inside diameter
96 mm
Nominal pressure of fitting PN
63
Medium
Vapor Neutral liquids
Flow rate Kv
429.7 m³/h
Seals material
FPM PTFE
Seat seal material
PTFE, modified
Mounting position
Any
Flange hole pattern
F10 F12
Valve function
2/2
Nominal width DN
100
Temperature of medium
-20 °C ... 200 °C

Material number for ball

1.4408/CF8M

Material number for shaft

1.4401

Corrosion resistance class (CRC)

4 - Particularly high corrosion stress

Fitting connection

Weld-on end according to ASME B16.11

Symbol

00991458

Ball material

Cast stainless steel

Certification

CRN

CE marking (see declaration of conformity)

as per EU pressure equipment directive

Design

2-way ball valve

Type of mounting

Line installation

Breakaway torque at differential pressure, nominal pressure, fitting PN

170 Nm

Housing material

Cast stainless steel

Product weight

18900 g

Explosion prevention and protection

Zone 1 (ATEX) Zone 22 (ATEX)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
