8072857 Festo Adapter Kits for Actuators
Part#:8072857
Alt. Part#:DADG-D-F8-16/20
Manufacturer:Festo
Category:Adapter Kits for Actuators
Product Lifecycle:Active
Product description
proximity sensor DADG-D-F8-16/20 Conforms to standard: EN 60947-5-2, Authorisation: (* RCM Mark, * c UL us (OL)), CE mark (see declaration of conformity): to EU directive for EMC, Materials note: (* Contains PWIS substances, * Conforms to RoHS), Nominal s
Product Details
- Certification RCM compliance mark c UL us (OL)
- Ambient temperature -25 °C ... 70 °C
- Switching element function N/O contact
- Voltage drop 2 V
- Reverse polarity protection for all electrical connections
- Cable length 2 m
- Mounting type Flush
- Conforms to standard EN 60947-5-2
- Repetition accuracy 0.01 mm
- Max. switching frequency 5000 Hz
- Idle current ≤ 10 mA
- Size M4
- Degree of protection IP67
- Type code DADG
- Electrical connection 1, connection type Cable
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Reduction factors Aluminum = 0.55 Steel St 37 = 1.0
- Max. output current 100 mA
- DC operating voltage range 10 V ... 30 V
- Type of mounting Screwed tightly
- Housing material Steel
- Electrical connection 1, connection technology Open end
- Symbol 00991702
- CE marking (see declaration of conformity) As per EU EMC directive
- Assured operating distance 0.64 mm
- Max. switching frequency DC 5000 Hz
- Material of cable sheath TPE-U(PUR)
- Electrical connection 1, number of pins/wires 3
- Rated operating distance 0.6 mm
- Switching output PNP
- Short-circuit protection Pulsed
- Residual ripple 10 %
- Product weight 26 g
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
