8065135 Festo Cable Assemblies

Product Details

• Type code
  NEBC
• Shield
  yes
• Electrical connection 1, function
  Control side
• Electrical connection 1, number of pins/wires
  4
• Nominal conductor cross section
  AWG22
• Electrical connection 1, design
  Round
• Product weight
  875 g
• Electrical connection 1, cable outlet
  Straight
• Electrical connection 2, connection type
  Plug
• Electrical connection 2, connection technology
  M8x1, D-coded as per EN 61076-2-114
• Electrical connection 2, type of mounting
  Screw-type lock with longitudinal knurl
• Surge resistance
  1.5 kV
• Ambient temperature with flexible cable installation
  -5 °C ... 60 °C
• Housing colour
  Black
• Based on norm
  EN 61076-2-114
• Electrical connection 1, connection type
  Plug
• Electrical connection 1, occupied pins/wires
  4
• Electrical connection for input 1, connection pattern
  00995938
• Electrical connection 2, occupied pins/wires
  4
• Nominal operating voltage DC
  24 V
Cable length
15 m
Bending radius, flexible cable installation
≥ 75 mm
Degree of protection
IP65 IP67
Special features
Oil-resistant
Storage temperature
-40 °C ... 70 °C
Color cable sheath
Silver-grey with sky blue stripe
Seals material
NBR
Cable designation
Without label holder
Contact durability
100
Electrical connection 1, connection technology
M8x1, D-coded as per EN 61076-2-114
Electrical connection 2, design
Round
Electrical connection 2, connection pattern
00995938
Reverse polarity protection
no
Cable characteristic
Suitable for energy chains
Cable diameter tolerance
± 0.2 mm
Contamination level
3
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Insulating sheath material
PP
Electrical connection 1, type of mounting
Screw-type lock with longitudinal knurl
Electrical connection 2, cable outlet
Straight
Current rating at 40°C
3 A
Connector cable test conditions
Test conditions on request
Cable diameter
6.3 mm
Note on degree of protection
In mounted state
Note on materials
RoHS-compliant Halogen-free
Housing material
PA TPE-U(PUR)
Material of screw-type lock
Brass, nickel-plated
Material of pin contacts
Copper alloy, gold-plated
Electrical connection 2, function
Control side
Electrical connection 2, number of pins/wires
4
DC operating voltage range
0 V ... 30 V
Protective earth connection
Not available
Bending radius, fixed cable installation
≥ 20 mm
Cable design
1 x (4 x AWG22)
Ambient temperature
-20 °C ... 60 °C
Material of cable sheath
TPE-U(PUR)
Transmission characteristics
as per system communication AP
