8060543 Festo Angle Seat Valves
Part#:8060543
Alt. Part#:VZXA-B-TS7-3/4"-M2-V14T-30-K-75-20-V4
Manufacturer:Festo
Category:Angle Seat Valves
Product Lifecycle:Active
Product description
angle seat valve VZXA-B-TS7-3/4"-M2-V14T-30-K-75-20-V4 Modular, pneumatically actuated angle seat valve in stainless steel. Under seat version, safety position closed, NPT thread, nominal width 3/4". Design structure: Poppet valve with piston actuator, Ty
Product Details
- PFH 1.36E-7
- Medium pressure 0 bar ... 30 bar
- Actuation type Pneumatic
- Valve function 2/2
- Pneumatic connection Internal thread G1/8
- Max. viscosity 600 mm²/s
- Material number, fitting housing ASTM A351-CF3M
- Certificate issuing authority CRN0C20829.5C German Technical Control Board (TÜV) 968/V 1039.00/18
- Certification CRN
- Type of mounting Line installation
- Reset method Mechanical spring
- Control of the medium On/off mode
- Ambient temperature 0 °C ... 60 °C
- Valve housing material Cast stainless steel
- Actuator size 75 mm
- Degree of protection IP65 IP67
- Safety integrity level (SIL) SIL 2
- Operating pressure 5 bar ... 10 bar
- Mounting position Any
- Flow direction Under valve seat, for gaseous and liquid media
- Medium Vapor Neutral liquids
- Temperature of medium -10 °C ... 180 °C
- Seals material FPM
- Stroke 20 mm
- Material number, drive housing 1.4408
- Storage temperature -10 °C ... 60 °C
- Use in exterior area wettergeschützte Einsatzorte Klasse C1 in Anlehnung an IEC 60654-1
- Cable connection Threaded sleeve 3/4 NPT as per ANSI/ASME B 1.20.1
- Symbol 00995586
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Seat seal material PTFE
- Position sensing With mechanical indicator
- Cover material Cast stainless steel
- Product weight 3360 g
- Type code VZXA
- PFD 5.95E-4
- Design Poppet valve with piston actuator
- Type of control Externally controlled
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Flow rate Kv 13.5 m³/h
- Spindle seal material PTFE
- Control function Closed by spring force, NC
- Explosion prevention and protection Zone 1 (ATEX) Zone 22 (ATEX)
- CE marking (see declaration of conformity) as per EU machinery directive
- Drive housing material Cast stainless steel
- Piston rod material High-alloy stainless steel
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
