576636 Festo Cable Assemblies

Product Details

• Cable diameter
  8 mm
• Type code
  NEBC
• Contact durability
  100
• Electrical connection 1, cable outlet
  Straight
• Electrical connection 1, type of mounting
  Screw-type lock with AF 14 and longitudinal knurl
• Electrical connection 2, connection type
  Hybrid plug
• Cable characteristic
  Standard
• Based on norm
  Dimensions as per EN 61076-2-101
• Electrical connection 1, function
  Field device end Control side
• Electrical connection 1, connection technology
  M12x1, with Festo-specific coding
• Electrical connection 2, design
  Round
• Electrical connection 2, type of mounting
  Screw-type lock with AF 14 and longitudinal knurl
• Note on acceptable current load at 40°C
  1.5 A for conductor cross-section of 0.14 mm²
• Connector cable test conditions
  Test conditions on request
• Cable design
  (1 x (4 x 0.14 mm²)) + 4 x 0.75 mm²
• Storage temperature
  -40 °C ... 70 °C
• Color cable sheath
  Light gray
• Housing colour
  Black
• Cable designation
  Without label holder
• Product weight
  280 g
Electrical connection 1, number of pins/wires
8
Electrical connection 2, function
Field device end Control side
Electrical connection 2, number of pins/wires
8
Current rating at 40°C
7 A
Surge resistance
0.8 kV
Cable diameter tolerance
± 0.2 mm
Degree of protection
IP65 IP67
Housing material
TPE-U(PUR)
Insulating sheath material
PP
Certification
c UL us - Recognized (OL)
Electrical connection 1, connection type
Hybrid plug
Electrical connection 1, design
Round
Electrical connection 2, cable outlet
Straight
Electrical connection 2, occupied pins/wires
8
Cable length
3 m
Bending radius, fixed cable installation
≥ 24 mm
Nominal conductor cross section
0.14 mm² 0.75 mm²
Ambient temperature with flexible cable installation
-5 °C ... 70 °C
Contamination level
3
Material of screw-type lock
Brass, nickel-plated
Electrical connection 1, occupied pins/wires
8
Electrical connection 2, connection technology
M12x1, with Festo-specific coding
DC operating voltage range
0 V ... 30 V
Bending radius, flexible cable installation
≥ 56 mm
Note on degree of protection
In mounted state
Note on materials
RoHS-compliant Halogen-free
Material of cable sheath
TPE-U(PUR)
Special features
Oil-resistant
Ambient temperature
-25 °C ... 70 °C
Corrosion resistance class (CRC)
1 - Low corrosion stress
Material of pin contacts
Brass, gold-plated
