575422 Festo Cable Assemblies
Part#:575422
Alt. Part#:NEBV-S1WA44-K-10-N-LE44-S9
Manufacturer:Festo
Category:Cable Assemblies
Product Lifecycle:Active
Product description
connecting cable NEBV-S1WA44-K-10-N-LE44-S9 Based on the standard: DIN 47100, Cable identification: Without inscription label holder, Connection frequency: 50, Product weight: 1660 g, Electrical connection 1, function: Field device side
Product Details
- Type code NEBV
- Product weight 1660 g
- Electrical connection 1, connection technology Sub-D
- Electrical connection for input 1, connection pattern 00995646
- Bending radius, fixed cable installation ≥ 42 mm
- Nominal conductor cross section 0.14 mm²
- Ambient temperature -35 °C ... 80 °C
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Material of pin contacts Bronze Gold-plated
- Cable designation Without label holder
- Electrical connection 1, design Rectangular
- Electrical connection 1, number of pins/wires 44
- Electrical connection 1, type of mounting 2x screw, 4-40 UNC
- Electrical connection 2, connection technology Open end
- Current rating at 40°C 0.86 A
- Cable length 10 m
- Reverse polarity protection yes
- Wire ends Cut off bluntly
- Storage temperature -35 °C ... 80 °C
- Color cable sheath Gray
- Material of screws Steel
- Cable fitting M20x1.5
- Electrical connection 1, function Field device end
- Electrical connection 1, occupied pins/wires 44
- Electrical connection 2, number of pins/wires 44
- DC operating voltage range 0 V ... 30 V
- Connector cable test conditions Test conditions on request
- Bending radius, flexible cable installation ≥ 126 mm
- Cable diameter tolerance ± 0.3 mm
- Degree of protection IP65 IP67
- Note on materials RoHS-compliant
- Housing material PA66-GF30
- Housing colour Black
- Contact durability 50
- Electrical connection 1, cable outlet Angled
- Electrical connection 2, function Control side
- Cable diameter 10.2 mm
- Note on degree of protection In mounted state
- Material of cable sheath PVC
- Based on norm DIN 47100
- Electrical connection 1, connection type Socket
- Electrical connection 2, connection type Cable
- Electrical connection 2, occupied pins/wires 44
- Surge resistance 2.4 kV
- Cable characteristic Standard
- Cable design 44 x 0.14 mm²
- Ambient temperature with flexible cable installation -5 °C ... 80 °C
- Contamination level 3
- Seals material NBR
- Insulating sheath material PVC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
