575125 Festo Proportional Valves

Product Details

• Exhaust nominal width
  4.5 mm
• Actuation type
  Electrical
• Reverse polarity protection
  for all electrical connections
• Display type
  Back-lit LCD
• KC characters
  KC EMC
• Safety instructions
  VPPM safety position: if the supply cable breaks, the outlet pressure is maintained in uncontrolled form.
• Pressure regulation range
  0.1 bar ... 10 bar
• Max. current consumption
  300 mA
• Max. electrical power consumption
  7 W
• Type code
  VPPM
• Short-circuit protection
  For all electrical connections
• Reset method
  Mechanical spring
• Valve function
  3-way proportional pressure control valve
• DC operating voltage range
  21.6 V ... 26.4 V
• Analog input signal range
  0 - 10 V
• Ambient temperature
  0 °C ... 50 °C
• Certification
  RCM compliance mark c UL us - Listed (OL)
• Temperature coefficient
  0.04 %/K
• Note on materials
  RoHS-compliant
• Mounting position
  Any
Symbol
00995303
Type of control
Pilot-controlled
Max. pressure hysteresis
0.05 bar
Residual ripple
10 %
Degree of protection
IP65
Linearity error FS
2 %
Pneumatic connection 2
G1/8
Nominal width pressurization
6 mm
Sealing principle
Soft
Design
Pilot-controlled diaphragm regulator
Inlet pressure 1
0 bar ... 11 bar
Duty cycle
100%
Analog output signal range
0 - 10 V
Information on operating and pilot media
Operation with oil lubrication not possible
Product weight
400 g
Repetition accuracy FS
0.5 %
Pneumatic connection 1
G1/8
Standard nominal flow rate
1400 l/min
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
CE marking (see declaration of conformity)
As per EU EMC directive
Electrical connection
8-pin Plug
Housing material
Wrought aluminum alloy Anodized
Temperature of medium
10 °C ... 50 °C
Type of mounting
Optionally: With accessories
Pneumatic connection 3
G1/8
