572411 Festo Proportional Valves

Product Details

• Type code
  VPPM
• Design
  Pilot-controlled diaphragm regulator
• Reset method
  Mechanical spring
• Display type
  Back-lit LCD
• Max. pressure hysteresis
  0.03 bar
• Max. current consumption
  300 mA
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Certification
  RCM compliance mark c UL us - Listed (OL)
• Temperature coefficient
  0.04 %/K
• Pneumatic connection 1
  Sub-base
• Housing material
  Wrought aluminum alloy Anodized
• KC characters
  KC EMC
• Sealing principle
  Soft
• Symbol
  00995303
• Pressure regulation range
  0.06 bar ... 6 bar
• Max. electrical power consumption
  7 W
• Degree of protection
  IP65
• Note on materials
  RoHS-compliant
• Exhaust nominal width
  7 mm
Actuation type
Electrical
Safety instructions
VPPM safety position: if the supply cable breaks, the outlet pressure is maintained in uncontrolled form.
Valve function
3-way proportional pressure control valve
Standard nominal flow rate
1050 l/min
Residual ripple
10 %
Temperature of medium
10 °C ... 50 °C
Product weight
560 g
Repetition accuracy FS
0.5 %
Pneumatic connection 2
Sub-base
Nominal width pressurization
8 mm
Mounting position
Any
Reverse polarity protection
for all electrical connections
Inlet pressure 1
0 bar ... 8 bar
Duty cycle
100%
Information on operating and pilot media
Operation with oil lubrication not possible
Ambient temperature
0 °C ... 50 °C
Electrical connection
Via sub-base
Pneumatic connection 3
Sub-base
Short-circuit protection
For all electrical connections
Type of control
Pilot-controlled
DC operating voltage range
21.6 V ... 26.4 V
CE marking (see declaration of conformity)
As per EU EMC directive
Linearity error FS
2 %
Type of mounting
Optionally: With accessories
