570517 Festo Pneumatic Tubing
Part#:570517
Alt. Part#:PEN-14X2-NT
Manufacturer:Festo
Category:Pneumatic Tubing
Product Lifecycle:Active
Product description
plastic tubing PEN-14X2-NT Outside diameter: 14 mm, Bending radius relevant for flow rate: 80 mm, Inside diameter: 9,5 mm, Min. bending radius: 45 mm, Tubing characteristics: Suitable for energy chains in applications with high cycle rates
Product Details
- Tubing characteristics Suitable for energy chains in applications with high cycle rates
- Type code PEN
- Color Natural
- Note on materials Free of copper and PTFE RoHS-compliant
- Outside diameter 14 mm
- Min. bending radius 45 mm
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
- Ambient temperature -30 °C ... 60 °C
- Product weight by length 0.0773 kg/m
- Pneumatic tubing test conditions Suitability for energy chains: >5 million cycles as per FN 942021
- Inside diameter 9.5 mm
- Shore hardness D 52 +/-3
- Bending radius relevant for flow rate 80 mm
- Temperature-dependent operating pressure -0.95 bar ... 10 bar
- Certification German Technical Control Board (TÜV)
- Material of pneumatic tubing PE
- Pneumatic connection For plug connection outside diameter 14 mm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
