570424 Festo Pneumatic Tubing

570424 on Powermatic Associates
Festo

Part#:570424

Alt. Part#:PLN-14X2-NT

Manufacturer:Festo

Category:Pneumatic Tubing

Product Lifecycle:Active

Product description

plastic tubing PLN-14X2-NT Outside diameter: 14 mm, Bending radius relevant for flow rate: 80 mm, Inside diameter: 10 mm, Min. bending radius: 40 mm, Temperature dependent operating pressure: -0,95 - 14 bar

Product Details

  • Certificate issuing authority
    B 013277 0506 00
  • Product weight by length
    0.07 kg/m
  • Min. bending radius
    40 mm
  • For use in the food industry
    See supplementary material information
  • Pneumatic connection
    For plug connection outside diameter 14 mm
  • Bending radius relevant for flow rate
    80 mm
  • Temperature-dependent operating pressure
    -0.95 bar ... 14 bar
  • Certification
    German Technical Control Board (TÜV)
  • Material of pneumatic tubing
    PE
  • Outside diameter
    14 mm
  • Type code
    PLN
  • Ambient temperature
    -30 °C ... 80 °C
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Inside diameter
    10 mm
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
  • Color
    Natural

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
