570354 Festo Pneumatic Tubing
Part#:570354
Alt. Part#:PUN-V0-16X2,5-BL-C
Manufacturer:Festo
Category:Pneumatic Tubing
Product Lifecycle:Active
Product description
plastic tubing PUN-V0-16X2,5-BL-C Flame retardant Outside diameter: 16 mm, Bending radius relevant for flow rate: 90 mm, Inside diameter: 11 mm, Min. bending radius: 50 mm, Tubing characteristics: Suitable for energy chains in applications with high cycle
Product Details
- Bending radius relevant for flow rate 90 mm
- Material fire test UL94 V-0 (3mm) UL94 V-2 (0.75mm)
- Color Blue
- Inside diameter 11 mm
- Ambient temperature -35 °C ... 60 °C
- Pneumatic connection For plug connection outside diameter 16 mm
- Shore hardness D 54 +/-3
- Outside diameter 16 mm
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
- Certification German Technical Control Board (TÜV)
- Information on color Deviates from the standard color due to flame protection
- Material of pneumatic tubing TPE-U(PU)
- Tubing characteristics Suitable for energy chains in applications with high cycle rates
- Type code PUN-V0
- Product weight by length 0.147 kg/m
- Pneumatic tubing test conditions Suitability for energy chains: >5 million cycles as per FN 942021
- Min. bending radius 50 mm
- Temperature-dependent operating pressure -0.95 bar ... 10 bar
- Note on materials Free of copper and PTFE RoHS-compliant
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
