569915 Festo Pneumatic Tubing

569915 on Powermatic Associates
Festo

Part#:569915

Alt. Part#:PLN-1/4-BL-150-CB

Manufacturer:Festo

Category:Pneumatic Tubing

Product Lifecycle:Active

Product description

plastic tubing PLN-1/4-BL-150-CB highly resistant to chemicals and hydrolysis. Outer diameter, inches: 1/4, Bending radius relevant for flow rate: 0,105 Fuß, Min. bending radius: 0,039 Fuß, Temperature dependent operating pressure: -14,4 - 203 Psi, Operat

Product Details

  • Bending radius relevant for flow rate
    32.004 mm
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
  • Pneumatic connection
    For plug connection outside diameter 1/4"
  • Material of pneumatic tubing
    PE
  • Product weight by length
    0.18 kg/m
  • Shore hardness
    D 52 +/-3
  • Temperature-dependent operating pressure
    -0.993 bar ... 13.996 bar
  • Color
    Blue
  • Min. bending radius
    11.887 mm
  • Ambient temperature
    -30 °C ... 80 °C
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • External-Ø inches
    1/4
  • Type code
    PLN
  • For use in the food industry
    See supplementary material information

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
