569882 Festo Pneumatic Tubing

569882 on Powermatic Associates
Festo

Part#:569882

Alt. Part#:PEN-3/16-SW-150-CB

Manufacturer:Festo

Category:Pneumatic Tubing

Product Lifecycle:Active

Product description

plastic tubing PEN-3/16-SW-150-CB standard O.D tubing, for QS plug connectors, polyethylene (not approved for use in the food industry). Outer diameter, inches: 3/16, Bending radius relevant for flow rate: 0,075 Fuß, Min. bending radius: 0,039 Fuß, Tubing

Product Details

  • Pneumatic tubing test conditions
    Suitability for energy chains: >5 million cycles as per FN 942021
  • External-Ø inches
    3/16
  • Temperature-dependent operating pressure
    -0.993 bar ... 9.997 bar
  • Ambient temperature
    -30 °C ... 60 °C
  • Material of pneumatic tubing
    PE
  • Tubing characteristics
    Suitable for energy chains in applications with high cycle rates
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
  • Color
    Black
  • Min. bending radius
    11.887 mm
  • Shore hardness
    D 52 +/-3
  • Bending radius relevant for flow rate
    22.86 mm
  • Product weight by length
    0.1 kg/m
  • Type code
    PEN
  • Pneumatic connection
    For plug connection outside diameter 3/16"
  • Note on materials
    Free of copper and PTFE RoHS-compliant

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
