568242 Festo Pneumatic Components

Product Details

• Design
  Rectangular
• CE marking (see declaration of conformity)
  As per EU EMC directive
• Analog output
  4 - 20 mA
• Short-circuit protection
  yes
• Max. cable length
  30 m
• Position indicator
  Yellow/black
• Insulation voltage
  50 V
• Type code
  SRAP
• Certification
  RCM compliance mark c UL us - Recognized (OL)
• Ambient temperature
  -20 °C ... 80 °C
• Idle current
  12 mA ... 20 mA
• Electrical connection
  9-pin Plug-in
• Cable fitting
  M20
• Angle detection setting range
  0 deg ... 270 deg
• Protection class
  III
• Based on norm
  VDI/VDE 3845 (NAMUR)
• Measured variable
  Rotation angle
• Repetition accuracy analog output in ± °
  1 deg
• Overload protection
  Available
• Mounting position
  Any
Setting options
Teach-in Teach-in via electrical connection
Contamination level
3
Measuring principle
Magnetic Hall
Reverse polarity protection
for all electrical connections
Approved cable diameter
5 mm ... 13 mm
Product weight
1000 g
Degree of protection
IP65
Corrosion resistance class (CRC)
3 - High corrosion stress
Note on materials
RoHS-compliant
DC operating voltage range
15 V ... 30 V
Closable nominal conductor cross-section
2.5 mm²
Housing material
Wrought aluminum alloy
Surge resistance
0.8 kV
