565710 Festo Electrical Connectors

565710 on Powermatic Associates
Festo

Part#:565710

Alt. Part#:NECU-L3G8-C2

Manufacturer:Festo

Category:Electrical Connectors

Product Lifecycle:Active

Product description

plug NECU-L3G8-C2 Connection frequency: 100, Assembly position: Any, Electrical connection: (* 8-pin, * Screwed terminal, * Plug straight), Operating voltage range DC: 0 - 30 V, Acceptable current load at 40°C: 12 A

Product Details

  • Electrical connection
    8-pin Plug, straight
  • Contamination level
    3
  • Mounting position
    Any
  • Ambient temperature
    -40 °C ... 85 °C
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Housing colour
    Black
  • Contact durability
    100
  • Connection cross section
    0.2 mm² ... 2.5 mm²
  • Housing material
    PA
  • DC operating voltage range
    0 V ... 30 V
  • Surge resistance
    4 kV
  • Type code
    NECU
  • Current rating at 40°C
    12 A
  • Note on materials
    RoHS-compliant
  • Material of pin contacts
    Copper alloy Tin-plated

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

565710 Related Documents

565710 DataSheet.pdf
