546963 Festo Pressure Gauges

Name: 546963
Brand: Festo

Part#:546963

Manufacturer:Festo

Alt. Part#:MA-40-2,5-R1/8-E-RG

Product Lifecycle:Active

Get a quick Quote!

pressure gauge MA-40-2,5-R1/8-E-RG With display unit in bar, adjustable red/green range. Indicating range [bar]: 0 - 2,5 bar, Conforms to standard: EN 837-1, Nominal size of pressure gauge: 40, Design structure: Bourdon-tube pressure gauge, Mounting type:

About the manufacturer: Festo is one of the manufacturers that offers Pressure Gauges that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 546963 Festo price in the box on the right side or send a quick quote.

Product Details

Display range
0 bar ... 2.5 bar
Operating medium
Inert gas Neutral liquids
Measurement accuracy class
2.5
Connection position
Centered on rear side
Product weight
60 g
Type code
MA
Pressure gauge nominal size
40
Intermittent load factor
0.66
Degree of protection
IP43
Material of screwed trunnion
Brass
Information on operating and pilot media
No acetylene No oxygen
Conforms to standard
EN 837-1
Type of mounting
Line installation
Operating pressure
0 bar ... 2.5 bar
Note on materials
RoHS-compliant
Inspection window material
PMMA
Explosion prevention and protection
Observe the information on the certificate Zone 22 (ATEX)
Ambient temperature
-20 °C ... 60 °C
Pneumatic connection
R1/8
Housing material
ABS

Symbol

00991463

Design

Bourdon tube pressure gauge

Temperature of medium

-20 °C ... 60 °C

Materials in contact with the media

Brass

Housing colour

Black

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
