546286 Festo Pneumatic Tubing

546286 on Powermatic Associates
Festo

Part#:546286

Alt. Part#:PAN-8X1,25-NT

Manufacturer:Festo

Category:Pneumatic Tubing

Product Lifecycle:Active

Product description

plastic tubing PAN-8X1,25-NT standard O.D. tubing, can withstand high thermal and mechanical loads. Outside diameter: 8 mm, Bending radius relevant for flow rate: 43 mm, Inside diameter: 5,9 mm, Min. bending radius: 22 mm, Tubing characteristics: Suitable

Product Details

  • Inside diameter
    5.9 mm
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Pneumatic connection
    For plug connection outside diameter 8 mm For barbed fitting, inside diameter 6 mm
  • Tubing characteristics
    Suitable for energy chains in applications with high cycle rates
  • Ambient temperature
    -30 °C ... 80 °C
  • Color
    Natural
  • Pneumatic tubing test conditions
    Suitability for energy chains: >5 million cycles as per FN 942021
  • Min. bending radius
    22 mm
  • Certificate issuing authority
    B 013277 0506 00
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Outside diameter
    8 mm
  • Temperature-dependent operating pressure
    -0.95 bar ... 15 bar
  • Certification
    German Technical Control Board (TÜV)
  • Material of pneumatic tubing
    TPE-A
  • Maritime classification
    See certificate
  • Bending radius relevant for flow rate
    43 mm
  • Type code
    PAN
  • Product weight by length
    0.024 kg/m
  • Shore hardness
    D 55 +/-3

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
