543315 Festo Vacuum Generators
Part#:543315
Alt. Part#:VN-10-L-T3-PI4-VA4-RO1
Manufacturer:Festo
Category:Vacuum Generators
Product Lifecycle:Active
Product description
vacuum generator VN-10-L-T3-PI4-VA4-RO1 Standard, high suction rate, width 14 mm, T shape with female thread and open silencer. Vacuum connection with male thread. Nominal size, Laval nozzle: 0,95 mm, Grid dimension: 14 mm, Design, silencer: open, Assembl
Product Details
- Type code VN
- Ejector characteristics High suction rate Standard
- Operating pressure 1 bar ... 8 bar
- Information on operating and pilot media Operation with oil lubrication not possible
- Width dimension 14 mm
- Integrated function Pneumatic muffler open
- Nominal operating pressure 6 bar
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Temperature of medium 0 °C ... 60 °C
- Max. tightening torque 0.5 Nm
- Note on materials Free of copper and PTFE RoHS-compliant
- Muffler material PE
- Muffler construction type Open
- Design T-shape
- Air supply time at nominal operating pressure 0.46 s
- Pneumatic connection 1 G1/8
- Seals material NBR
- Nominal width of Laval nozzle 0.95 mm
- Max. suction rate with respect to atmosphere 62.7 l/min
- Noise level at nominal operating pressure 73 dB(A)
- Pneumatic connection 3 Pneumatic muffler open
- Female nozzle material POM
- Mounting position Any
- Operating pressure for max. suction rate 4 bar
- Symbol 00991489
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Ambient temperature 0 °C ... 60 °C
- Product weight 26 g
- Material of connecting thread Wrought aluminum alloy Brass, nickel-plated
- Housing material POM-reinforced
- Type of mounting With through-hole With accessories
- Vacuum connection G1/8
- Material of jet nozzle Wrought aluminum alloy
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
