542242 Festo Proportional Valves

Product Details

• Type code
  VPPM
• Mounting position
  Any
• Reset method
  Mechanical spring
• Max. pressure hysteresis
  0.01 bar
• Residual ripple
  10 %
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
• Degree of protection
  IP65
• Temperature coefficient
  0.04 %/K
• Electrical connection
  8-pin Plug
• Pneumatic connection 3
  Sub-base
• KC characters
  KC EMC
• Actuation type
  Electrical
• Symbol
  00995303
• Valve function
  3-way proportional pressure control valve
• Duty cycle
  100%
• Temperature of medium
  10 °C ... 50 °C
• Product weight
  400 g
• Pneumatic connection 1
  Sub-base
• Housing material
  Wrought aluminum alloy Anodized
• Exhaust nominal width
  4.5 mm
Sealing principle
Soft
Reverse polarity protection
for all electrical connections
Inlet pressure 1
0 bar ... 4 bar
Standard nominal flow rate
380 l/min
Max. current consumption
300 mA
Analog output signal range
4 - 20 mA
Certification
RCM compliance mark c UL us - Listed (OL)
Note on materials
RoHS-compliant
Safety instructions
VPPM safety position: if the supply cable breaks, the outlet pressure is maintained in uncontrolled form.
Type of control
Pilot-controlled
Display type
LED
Switching output
NPN
Information on operating and pilot media
Operation with oil lubrication not possible
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Linearity error FS
1 %
Repetition accuracy FS
0.5 %
Nominal width pressurization
6 mm
Design
Pilot-controlled diaphragm regulator
Short-circuit protection
For all electrical connections
Pressure regulation range
0.02 bar ... 2 bar
DC operating voltage range
21.6 V ... 26.4 V
Max. electrical power consumption
7 W
Analog input signal range
4 - 20 mA
CE marking (see declaration of conformity)
As per EU EMC directive
Ambient temperature
0 °C ... 60 °C
Type of mounting
Optionally: With accessories
Pneumatic connection 2
Sub-base
