541734 Festo Pressure Gauges

541734 on Powermatic Associates
Festo

Part#:541734

Alt. Part#:MA-27-25-R1/8

Manufacturer:Festo

Category:Pressure Gauges

Product Lifecycle:Active

Product description

pressure gauge MA-27-25-R1/8 With display unit in bar and psi. Indicating range [bar]: 0 - 25 bar, Nominal size of pressure gauge: 27, Design structure: Bourdon-tube pressure gauge, Mounting type: Line installation, Operating medium: (* Inert gases, * Neu

Product Details

  • Symbol
    00991463
  • Type of mounting
    Line installation
  • Degree of protection
    IP43
  • Connection position
    Centered on rear side
  • Housing colour
    Black
  • Pressure gauge nominal size
    27
  • Operating medium
    Inert gas Neutral liquids
  • Intermittent load factor
    0.66
  • Materials in contact with the media
    PA-reinforced
  • Information on operating and pilot media
    No acetylene No oxygen
  • Display range
    0 bar ... 25 bar
  • Explosion prevention and protection
    Observe the information on the certificate Zone 22 (ATEX)
  • Measurement accuracy class
    4
  • Note on materials
    RoHS-compliant
  • Housing material
    PA
  • Inspection window material
    PS
  • Design
    Bourdon tube pressure gauge
  • Ambient temperature
    0 °C ... 60 °C
  • Pneumatic connection
    R1/8
  • Product weight
    8 g
  • Type code
    MA
  • Operating pressure
    0 bar ... 25 bar
  • Temperature of medium
    0 °C ... 60 °C
  • Material of screwed trunnion
    PA-reinforced

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
