536800 Festo Vacuum Generators

Name: 536800
Brand: Festo

Part#:536800

Manufacturer:Festo

Alt. Part#:VN-07-H-T4-PQ2-VQ2-O1-P

Product Lifecycle:Active

Get a quick Quote!

vacuum generator VN-07-H-T4-PQ2-VQ2-O1-P With integrated vacuum switch. Standard, high vacuum, width 18 mm, T shape with plug connector and open silencer. Nominal size, Laval nozzle: 0,7 mm, Grid dimension: 16 mm, Design, silencer: open, Assembly position

About the manufacturer: Festo is one of the manufacturers that offers Vacuum Generators that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 536800 Festo price in the box on the right side or send a quick quote.

Product Details

Switching function
Threshold value comparator Threshold value with fixed hysteresis
Setting range threshold value
-1 bar ... 0 bar
KC characters
KC EMC
Muffler construction type
Open
Design
T-shape
Measuring principle
Piezoresistive
Symbol
00991917
Operating pressure for max. suction rate
3 bar
Switch-off time
≤ 4 ms
Residual ripple
10 %
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Type code
VN
Integrated function
Pneumatic muffler open Vacuum switch
Method of measurement
Relative
Switching element function
N/O contact
Display type
LED
DC operating voltage range
15 V ... 30 V
Max. output current
100 mA
Voltage drop
≤ 1.5 V
CE marking (see declaration of conformity)
As per EU EMC directive

Ambient temperature

0 °C ... 50 °C

Pressure measuring range

-1 bar ... 0 bar

Temperature coefficient of switching point

0.05 %/K

Width dimension

16 mm

Ejector characteristics

High vacuum Standard

Measured variable

Relative pressure

Reverse polarity protection

for all electrical connections

Switching status indication

LED

Max. vacuum

92 %

Residual current

≤ 0.3 mA

Overload protection

Available

Information on operating and pilot media

Operation with oil lubrication not possible

Temperature of medium

0 °C ... 60 °C

Certification

RCM compliance mark

Max. tightening torque

0.6 Nm

Type of mounting

With through-hole

Pneumatic connection 3

Pneumatic muffler open

Housing material

POM-reinforced

Material of jet nozzle

Wrought aluminum alloy

Nominal width of Laval nozzle

0.7 mm

Mounting position

Any

Short-circuit protection

Pulsed

Setting options

Teach-in

Operating pressure for max. vacuum

4.4 bar

Operating pressure

1 bar ... 8 bar

On time

≤ 4 ms

Switching output

PNP

Cleaning advice

Soap suds

Product weight

36 g

Long-term drift

±0.5 % FS max.

Vacuum connection

QS-6

Female nozzle material

POM

Material of pneumatic fitting

Brass Nickel-plated

Nominal operating pressure

6 bar

Max. suction rate with respect to atmosphere

16.2 l/min

Inductive protective circuit

Adapted to MZ, MY and ME coils

Corrosion resistance class (CRC)

1 - Low corrosion stress

Degree of protection

IP40

Accuracy in ± % FS

1.5 %FS

Seals material

NBR

Material of keypad

POM

Noise level at nominal operating pressure

66 dB(A)

Hysteresis in ± %FS

2 %FS

Pneumatic connection 1

QS-6

Fiber-optic cable

Electrical connection

3-pin M8

Muffler material

Material of plug housing

Brass Chrome-plated and nickel-plated

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
