535753 Festo Compressed Air Preparation Units

535753 on Powermatic Associates
Festo

Part#:535753

Alt. Part#:MS4N-LFR-1/4-D7-CUV-AS-Z

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

11 in stock

Apr 2, 2025

Product description

filter regulator MS4N-LFR-1/4-D7-CUV-AS-Z Maximum output pressure 12 bar, 5 µm filter, with pressure gauge, lockable regulator head, metal bowl guard, fully automatic condensate drain, flow direction from right to left. Size: 4, Series: MS, Actuator lock:

Product Details

  • For use in the food industry
    See supplementary material information
  • Grade of filtration
    5 µm
  • Condensate drain
    Fully automatic
  • Max. condensate volume
    25 ml
  • Symbol
    00991587
  • Pressure gauge
    with pressure gauge
  • Operating pressure
    2 bar ... 12 bar
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:-] Inert gas
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Temperature of medium
    5 °C ... 60 °C
  • Pneumatic connection 1
    NPT1/4-18
  • Pneumatic connection 2
    NPT1/4-18
  • Seals material
    NBR
  • Compressed air filter material
    PE
  • Material of bowl
    Die-cast aluminum Wrought aluminum alloy
  • Inspection window material
    PA
  • Series
    MS
  • Type code
    MS4N-LFR
  • Actuator lock
    Rotary knob with detent can be closed with accessories
  • Controller function
    Outlet pressure constant With return flow function
  • Design
    Filter regulator with pressure gauge
  • Pressure regulation range
    0.5 bar ... 12 bar
  • Max. pressure hysteresis
    0.25 bar
  • Storage temperature
    -10 °C ... 60 °C
  • Air quality class at the output
    Compressed air as per ISO 8573-1:2010 [6:4:4]
  • Product weight
    475 g
  • Type of mounting
    Optionally: With accessories
  • Note on materials
    RoHS-compliant
  • Material of sub-base
    Die-cast aluminum
  • Housing material
    Die-cast aluminum
  • Separating disc material
    POM
  • Size
    4
  • Mounting position
    Vertical +/- 5°
  • Bowl guard
    Integrated as metal bowl guard
  • Standard nominal flow rate
    1200 l/min
  • Ambient temperature
    5 °C ... 60 °C
  • Material of operator panel
    PA POM
  • Diaphragm material
    NBR

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
