530005 Festo Compressed Air Preparation Units

530005 on Powermatic Associates
Festo

Part#:530005

Alt. Part#:MS6-LR-3/8-D7-AS

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Product description

pressure regulator MS6-LR-3/8-D7-AS 12 bar maximum output pressure, with pressure gauge, lockable regulator head, direction of flow: from left to right. Size: 6, Series: MS, Actuator lock: (* Rotary knob with lock, * with accessories, lockable), Assembly

Product Details

  • Type code
    MS6-LR
  • Operating pressure
    0.8 bar ... 20 bar
  • Standard nominal flow rate
    4500 l/min
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Material of operator panel
    PA POM
  • Separating disc material
    POM
  • For use in the food industry
    See supplementary material information
  • Pressure regulation range
    0.5 bar ... 12 bar
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Type of mounting
    Optionally: With accessories
  • Product weight
    730 g
  • Diaphragm material
    NBR
  • Actuator lock
    Rotary knob with detent can be closed with accessories
  • Controller function
    Outlet pressure constant With secondary exhausting
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
  • Ambient temperature
    -10 °C ... 60 °C
  • Pneumatic connection 1
    G3/8
  • Seals material
    NBR
  • Size
    6
  • Mounting position
    Any
  • Pressure gauge
    with pressure gauge
  • Symbol
    00991558
  • Temperature of medium
    -10 °C ... 60 °C
  • Note on materials
    RoHS-compliant
  • Housing material
    Die-cast aluminum
  • Series
    MS
  • Design
    Pressure regulator with pressure gauge
  • Max. pressure hysteresis
    0.25 bar
  • Storage temperature
    -10 °C ... 60 °C
  • Pneumatic connection 2
    G3/8
  • Compressed air filter material
    PE

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
