527544 Festo Cable Assemblies

Product Details

• Contact durability
  50
• Electrical connection 1, cable outlet
  Straight
• Electrical connection 2, function
  Control side
• DC operating voltage range
  0 V ... 30 V
• Connector cable test conditions
  Test conditions on request
• Cable diameter tolerance
  ± 0.25 mm
• Note on degree of protection
  In mounted state
• Ambient temperature
  -25 °C ... 70 °C
• Housing colour
  Gray
• Conforms to standard
  DIN 41652
• Electrical connection 1, design
  Rectangular
• Electrical connection 1, occupied pins/wires
  15
• Electrical connection for input 1, connection pattern
  00995640
• Cable length
  5 m
• Bending radius, flexible cable installation
  ≥ 129 mm
• Wire ends
  Cut off bluntly
• CE marking (see declaration of conformity)
  As per EU RoHS directive
• Contamination level
  2
• Housing material
  PBT-reinforced
• Type code
  KMP6
Electrical connection 1, function
Field device end
Electrical connection 1, number of pins/wires
15
Electrical connection 2, connection type
Cable
Nominal operating voltage DC
24 V
Bending radius, fixed cable installation
≥ 86 mm
Nominal conductor cross section
0.34 mm²
Storage temperature
-20 °C ... 75 °C
Color cable sheath
Gray
Product weight
585 g
Electrical connection 1, connection technology
Sub-D
Electrical connection 2, connection technology
Open end
Electrical connection 2, number of pins/wires
15
Current rating at 40°C
2.8 A
Cable design
15 x 0.34 mm²
Ambient temperature with flexible cable installation
-5 °C ... 70 °C
Material of screw-type lock
Brass, nickel-plated
Cable designation
Without label holder
Electrical connection 1, connection type
Socket
Electrical connection 1, type of mounting
2x screw, 4-40 UNC
Electrical connection 2, occupied pins/wires
15
Surge resistance
1 kV
Cable characteristic
Standard
Cable diameter
8.6 mm
Degree of protection
IP40
Material of cable sheath
PVC
Note on materials
RoHS-compliant
Material of pin contacts
Copper alloy, gold-plated
