527405 Festo Pressure Gauges

Name: 527405
Brand: Festo

Part#:527405

Alt. Part#:MA-27-160-M5-PSI

Manufacturer:Festo

Category:Pressure Gauges

Product Lifecycle:Active

Product description

pressure gauge MA-27-160-M5-PSI With display unit in psi. Indicating range [psi]: 0 - 160 psi, Nominal size of pressure gauge: 27, Design structure: Bourdon-tube pressure gauge, Mounting type: Line installation, Operating medium: (* Inert gases, * Neutral

Product Details

Type code
MA
Design
Bourdon tube pressure gauge
Operating pressure
0 bar ... 11.032 bar
Ambient temperature
0 °C ... 60 °C
Material of screwed trunnion
Brass
Housing colour
Black
Temperature of medium
0 °C ... 60 °C
Pneumatic connection
M5
Symbol
00991463
Pressure gauge nominal size
27
Type of mounting
Line installation
Intermittent load factor
0.66
Note on materials
RoHS-compliant
Housing material
PA
Product weight
11 g
Operating medium
Inert gas Neutral liquids
Measurement accuracy class
4
Connection position
Centered on rear side
Inspection window material
PS
Information on operating and pilot media
No acetylene No oxygen

Display range

0 psi ... 160 psi

Explosion prevention and protection

Observe the information on the certificate Zone 22 (ATEX)

Degree of protection

IP43

Materials in contact with the media

Brass

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

527405 Related Documents

527405 DataSheet.pdf
