526008 Festo Vacuum Cups

526008 on Powermatic Associates
Festo

Part#:526008

Alt. Part#:ESV-80-BT

Manufacturer:Festo

Category:Vacuum Cups

Product Lifecycle:Active

Product description

vacuum suction cup ESV-80-BT Wearing part, easily replaceable Height compensator for suction-cup holder: 10,5 mm, Min. workpiece radius: 100 mm, suction cup diameter: 80 mm, suction cup volume: 59,1 cm3, Assembly position: Any

Product Details

  • Suction cup volume
    59.1 cm³
  • Suction cup shape
    Round bellows, 1.5 convolutions
  • Breakaway force at 70% vacuum
    237 N
  • Shore hardness
    72 +/- 5
  • Symbol
    00991485
  • Ambient temperature
    -10 °C ... 80 °C
  • Color
    Reddish brown
  • Suction cup material
    Vulkollan®
  • Min. workpiece radius
    100 mm
  • Type code
    ESV
  • Operating pressure
    -0.95 bar ... 0 bar
  • Holding force at nominal operating pressure
    237 N
  • Suction cup diameter
    80 mm
  • Mounting position
    Any
  • Operating medium
    Atmospheric air based on ISO 8573-1:2010 [7:-:-]
  • Product weight
    57.2 g
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Suction cup holder height compensator
    10.5 mm
  • Design
    Bellows
  • Nominal operating pressure
    -0.7 bar
  • Lateral force at nominal operating pressure
    102 N
  • Type of mounting
    Via vacuum connection

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
