526003 Festo Vacuum Cups

Name: 526003
Brand: Festo

Part#:526003

Alt. Part#:ESV-60-GT

Manufacturer:Festo

Category:Vacuum Cups

Product Lifecycle:Active

Product description

vacuum suction cup ESV-60-GT Wearing part, easily replaceable Height compensator for suction-cup holder: 6 mm, Min. workpiece radius: 75 mm, suction cup diameter: 60 mm, suction cup volume: 11,3 cm3, Assembly position: Any

Product Details

Operating medium
Atmospheric air based on ISO 8573-1:2010 [7:-:-]
Holding force at nominal operating pressure
134 N
Note on materials
Free of copper and PTFE RoHS-compliant
Suction cup holder height compensator
6 mm
Design
Round, bell-shaped
Ambient temperature
-10 °C ... 80 °C
Shore hardness
72 +/- 5
Suction cup diameter
60 mm
Mounting position
Any
Symbol
00991485
Lateral force at nominal operating pressure
37 N
Product weight
10.7 g
Suction cup volume
11.3 cm³
Suction cup shape
Round, deep
Nominal operating pressure
-0.7 bar
Type of mounting
Via vacuum connection
Min. workpiece radius
75 mm
Type code
ESV
Operating pressure
-0.95 bar ... 0 bar
Breakaway force at 70% vacuum
134 N

Color

Reddish brown

Suction cup material

Vulkollan®

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
