5219197 Festo Cable Assemblies

5219197 on Powermatic Associates
Festo

Part#:5219197

Alt. Part#:NEBM-H6G4-E-2.5-Q13N-LE4

Manufacturer:Festo

Category:Cable Assemblies

Product Lifecycle:Active

Product description

motor cable NEBM-H6G4-E-2.5-Q13N-LE4 Cable identification: Without inscription label holder, Electrical connection 1, function: Field device side, Electrical connection 1, design: Angular, Electrical connection 1, connection type: Plug socket, Electrical

Product Details

  • Electrical connection 2, function
    Control side
  • Electrical connection 2, occupied pins/wires
    4
  • Surge resistance
    2 kV
  • Wire ends
    Cable end sleeve
  • Ambient temperature with flexible cable installation
    -25 °C ... 90 °C
  • Color cable sheath
    Black
  • Nominal conductor cross section
    0.79 mm²
  • Electrical connection 1, connection type
    Socket
  • Electrical connection 1, occupied pins/wires
    4
  • Electrical connection 2, number of pins/wires
    4
  • Current rating at 40°C
    9.5 A
  • Bending radius, flexible cable installation
    ≥ 55 mm
  • Degree of protection
    IP20
  • Corrosion resistance class (CRC)
    0 - No corrosion stress
  • Type code
    NEBM
  • Electrical connection 1, design
    Rectangular
  • Electrical connection 1, connection technology
    Connection diagram H6, coded for motor
  • Electrical connection 2, connection type
    Cable
  • DC operating voltage range
    0 V ... 300 V
  • Cable length
    2.5 m
  • Cable diameter
    7.3 mm
  • CE marking (see declaration of conformity)
    As per EU low voltage directive As per EU RoHS directive
  • Material of cable sheath
    PVC
  • Cable designation
    Without label holder
  • Electrical connection 1, cable outlet
    Straight
  • Electrical connection 2, connection technology
    Open end
  • Bending radius, fixed cable installation
    ≥ 55 mm
  • Connector cable test conditions
    Test conditions on request
  • Ambient temperature
    -25 °C ... 90 °C
  • Contamination level
    3
  • Housing colour
    White
  • Electrical connection 1, function
    Field device end
  • Electrical connection for input 1, connection pattern
    00995790
  • Electrical connection 1, number of pins/wires
    4
  • Operating voltage range AC
    0 V ... 300 V
  • Cable characteristic
    Suitable for energy chains
  • Cable design
    4 x 0.79 mm²
  • Note on degree of protection
    In mounted state
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Housing material
    PA
  • Insulating sheath material
    PVC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
