4802244 Festo Ball Valves

4802244 on Powermatic Associates
Festo

Part#:4802244

Alt. Part#:VZBD-1/2-S5-16-T-2-F0304-V14V14

Manufacturer:Festo

Category:Ball Valves

Product Lifecycle:Active

Product description

ball valve VZBD-1/2-S5-16-T-2-F0304-V14V14 Stainless steel for use in the cosmetics and pharmaceutical industry, 2/2-way, nominal width 1/2", top flange F0304, PN16, clamp ferrule to DIN 32676-B, electropolished. Design structure: 2-way ball valve, Type o

Product Details

  • Type of mounting
    Line installation
  • Breakaway torque at differential pressure, nominal pressure, fitting PN
    7 Nm
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Shaft material
    High-alloy stainless steel
  • Explosion prevention and protection
    Zone 1 (ATEX) Zone 22 (ATEX)
  • Type code
    VZBD
  • Sealing principle
    Soft
  • Flange hole pattern
    F0304
  • Nominal pressure of fitting PN
    16
  • Flow rate Kv
    12.2 m³/h
  • Ball material
    Cast stainless steel
  • Seat seal material
    PTFE, modified
  • Mounting position
    Any
  • Inside diameter
    18.1 mm
  • Flow direction
    Reversible
  • Temperature of medium
    -20 °C ... 200 °C
  • Seals material
    FPM PTFE
  • Material number for ball
    1.4409
  • Corrosion resistance class (CRC)
    4 - Particularly high corrosion stress
  • Design
    2-way ball valve
  • Fitting connection
    Clamp as per DIN 32676 series A
  • Nominal width DN
    15
  • Based on norm
    DIN 32676 ISO 5211
  • Medium
    Vapor Neutral liquids
  • Housing material
    Cast stainless steel
  • Material number for shaft
    1.4401
  • Certification
    3-A sanitary CRN
  • Actuation type
    Mechanical
  • Switching position indication
    Slot direction = flow direction
  • Valve function
    2/2
  • Symbol
    00991458
  • For use in the food industry
    See supplementary material information
  • Material number of housing
    1.4409
  • Product weight
    830 g

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

4802244 Related Documents

4802244 DataSheet.pdf
