3679772 Festo Cable Assemblies
Part#:3679772
Alt. Part#:NEBV-A1W3F-P-K-0.6-N-M12W3
Manufacturer:Festo
Category:Cable Assemblies
Product Lifecycle:Active
Product description
connecting cable NEBV-A1W3F-P-K-0.6-N-M12W3 Authorisation: c CSA us (OL), Operating status display: Yellow LED, Additional functions: Protective circuit, Cable identification: Without inscription label holder, Product weight: 100 g
Product Details
- Additional functions Protective circuit
- Electrical connection 1, function Field device end
- Electrical connection 1, connection type Socket
- Electrical connection 2, function Control side
- Electrical connection 2, number of pins/wires 5
- DC operating voltage range 18 V ... 30 V
- Protective earth connection Available
- Cable design 3 x 0.75 mm²
- Ambient temperature with flexible cable installation -25 °C ... 80 °C
- Material of union nut Die-cast zinc Nickel-plated
- Certification c CSA us (OL)
- Product weight 100 g
- Electrical connection 1, number of pins/wires 4
- Electrical connection 2, connection type Plug
- Electrical connection 2, connection technology M12x1 A-coded as per EN 61076-2-101
- Electrical connection 2, connection pattern 00995711
- Nominal operating voltage DC 24 V
- Surge resistance 0.8 kV
- Degree of protection IP67
- CE marking (see declaration of conformity) As per EU RoHS directive
- Housing material TPE-U(PUR)
- Cable designation Without label holder
- Electrical connection 1, design Rectangular
- Electrical connection for input 1, connection pattern 00995710
- Electrical connection 2, occupied pins/wires 3
- Operating voltage range AC 18 V ... 30 V
- Cable characteristic Standard
- Connector cable test conditions Test conditions on request
- Material of cable sheath TPE-U(PUR)
- Housing colour Black
- Switching status indication LED yellow
- Electrical connection 1, connection technology Connection diagram form A based on EN 175301-803
- Electrical connection 1, occupied pins/wires 4
- Electrical connection 2, cable outlet Angled
- Electrical connection 2, type of mounting Screw-type lock with hexagon, AF 13
- Current rating at 40°C 4 A
- Cable diameter 5.9 mm
- Note on degree of protection In mounted state
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Color cable sheath Gray
- Insulating sheath material PP
- Type code NEBV
- Electrical connection 1, cable outlet Angled
- Electrical connection 1, type of mounting On air solenoid valve with M3 central screw
- Electrical connection 2, design Round
- Nominal operating voltage AC 24 V
- Cable length 0.6 m
- Cable diameter tolerance ± 0.3 mm
- Ambient temperature -25 °C ... 80 °C
- Contamination level 3
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
