3539367 Festo Process & Media Valves
Part#:3539367
Alt. Part#:VZXF-L-M22C-M-A-G112-350-H3B1V-50-V
Manufacturer:Festo
Category:Process & Media Valves
Product Lifecycle:Active
Product description
angle seat valve VZXF-L-M22C-M-A-G112-350-H3B1V-50-V Pneumatically actuated angle seat valve in red brass. Over seat version, safety position closed, G thread, vacuum, nominal width 1 1/2". Design structure: Poppet valve with piston actuator, Type of actu
Product Details
- Cable connection Threaded sleeve G1 1/2 as per DIN ISO 228
- Nominal width 35 mm
- Flow direction Above valve seat, for gaseous media
- Symbol 00991367
- Ambient temperature -10 °C ... 60 °C
- Valve housing material Red brass
- Product weight 2300 g
- Type code VZXF
- Valve function 2/2, closed, monostable
- Medium pressure -0.9 bar ... 0 bar
- Exhaust air function Without flow control option
- Reset method Mechanical spring
- Max. viscosity 600 mm²/s
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Actuation type Pneumatic
- Mounting position Any
- Type of mounting Line installation
- Pneumatic connection Internal thread G1/8
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Material number, fitting housing CC499K
- Design Poppet valve with piston actuator
- Sealing principle Soft
- Type of control Externally controlled
- Medium Vapor Filtered compressed air, 200 µm filter mesh
- Flow rate Kv 23 m³/h
- Seat seal material FPM
- Nominal pressure of fitting PN 16
- Operating pressure 6 bar ... 10 bar
- Temperature of medium -10 °C ... 80 °C
- Spindle seal material FPM
- Drive housing material Brass
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
