3535644 Festo Process & Media Valves
Part#:3535644
Alt. Part#:VZXF-L-M22C-M-B-G34-160-M1-H3B1T-50-16
Manufacturer:Festo
Category:Process & Media Valves
Product Lifecycle:Active
Product description
angle seat valve VZXF-L-M22C-M-B-G34-160-M1-H3B1T-50-16 Pneumatically actuated angle seat valve in red brass. Under seat version, safety position closed, G thread, nominal width 3/4". Design structure: Poppet valve with piston actuator, Type of actuation:
Product Details
- Valve function 2/2, closed, monostable
- Type of control Externally controlled
- Temperature of medium -40 °C ... 200 °C
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Design Poppet valve with piston actuator
- Type code VZXF
- Cable connection Threaded sleeve G3/4 as per DIN ISO 228
- Medium pressure 0 bar ... 16 bar
- Pneumatic connection Internal thread G1/8
- Medium Vapor Neutral liquids
- Valve housing material Red brass
- Spindle seal material PTFE
- Product weight 1300 g
- Mounting position Any
- Nominal pressure of fitting PN 16
- Operating pressure 6 bar ... 10 bar
- Flow rate Kv 5.2 m³/h
- Seat seal material PTFE
- Actuation type Pneumatic
- Sealing principle Soft
- Flow direction Under valve seat, for gaseous and liquid media
- Reset method Mechanical spring
- Symbol 00991367
- Max. viscosity 600 mm²/s
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Ambient temperature -10 °C ... 60 °C
- Drive housing material Brass
- Type of mounting Line installation
- Nominal width 16 mm
- Exhaust air function Without flow control option
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Material number, fitting housing CC499K
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
